– Description and Handling – 5
221
Shield contact: Test slot:
with solder/crimp quick disconnect terminal for test plug 2 mm Ø or 2.3 mm Ø – with direct contact
(2.5 x 0.8) mm. to the current bar.
5
Terminal block marking:
with WMB (center position) and miniature WSB markers
(on the sides) – also see Section 13.
fine-stranded, fine-stranded,
fine-stranded, with ferrule 1 with pin terminal
tip-bonded (gastight crimped) (gastight crimped)
1 When using ferrules, the max. conductor cross section accommodated is one size smaller than max. rating of terminal block.
