X-COM -SYSTEM
®
6 1-Conductor/1-Conductor Disconnect Carrier Terminal Blocks
324 with 2 Jumper Positions
0.08 - 4 mm² AWG 28 - 12
400 V/6 kV/3 1
I N 16 A
Terminal block width 5 mm / 0.197 in
L 8 - 9 mm / 0.33 in 2

1 400 V = rated voltage
6 kV = rated surge voltage
3 = pollution degree
250 V/4 kV/3 =
ominal voltage with shield contact
<_ 28,5 mm/ _> 1.12 in 2 Strip length, see packaging or instructions.
(also see Section 14)
3 See application notes for:
Test plug modules, pages 288 – 290
Insulation stop, page 293
<___ 46 mm/1.81 in ___> Staggered jumper, page 295
<____________ 87,5 mm/3.44 in _____________> Push-in type wire jumper, page 295
Pack. Accessories
Item No.
Unit
1-conductor/1-conductor disconnect carrier terminal Appropriate marking system:
block with 2 jumper positions, Miniature WSB (see Section 13)
for DIN 35 rail, acc. to EN 60715 Staggered jumper, Miniature WSB Quick marking system,
gray 769-242 50 3 insulated, 10 strips with 10 markers per card,
Spacing: 5 mm, 5 mm wide markers
1-conductor/1-conductor disconnect carrier terminal I N 24 A plain 248-501 5
block with shield contact and with 2 jumper posi- from 1 to 2 780-452 100 (4x25) Miniature WSB Quick marking system, plain,
tions, (no picture), from 1 to 3 780-453 100 (4x25) 10 strips with 10 markers per card,
for DIN 35 rail, acc. to EN 60715 from 1 to 4 780-454 100 (4x25) 5 mm wide markers
gray 769-243 1 50 from 1 to 5 780-455 50 (2x25) yellow 248-501/000-002
769 Series Accessories from 1 to 6 780-456 50 (2x25) red 248-501/000-005
from 1 to 7 780-457 50 (2x25) blue 248-501/000-006
from 1 to 8 780-458 50 (2x25) gray 248-501/000-007
orange 248-501/000-012
End and intermediate plate, 1.1 mm thick Protective warning marker, light green 248-501/000-017
orange 769-318 100 (4x25) with high-voltage symbol, black, green 248-501/000-023
gray 769-317 100 (4x25) for 5 terminal blocks violet 248-501/000-024
yellow 280-415 100 (4x25) 5
Seperator plate, oversized, 1.1 mm thick Disconnect lock,
orange 769-319 100 (4x25) for disconnect tab used on 280/281 and
769 Series disconnect terminal blocks
red 709-170 200 (8x25)
Insulation stop, Test plug module,
3 5 pcs/strip, 3 can be snapped together,
0.08 - 0.2 mm² “s” (0.14 mm² “f-st”) 5 mm wide
white 769-470 200 (8x25) gray 280-418 100 (4x25)
Insulation stop, Spacer module,
3 5 pcs/strip, can be snapped together,
0.25 - 0.5 mm² 5 mm wide
light gray 769-471 200 (8x25) gray 280-419 100 (4x25)
Insulation stop, Test plug adapter, 5 mm wide,
3 5 pcs/strip, for terminal blocks 1.5 - 4 mm²,
0.75 - 1 mm² for 210-137 test plug 2.3 mm Ø
dark gray 769-472 200 (8x25) gray 280-404 100 (4x25)
Adjacent jumper, insulated, Test plug,
I N = I N terminal block with 500 mm cable,
gray 280-402 200 (8x25) 2 mm Ø
red 210-136 50
Alternate jumper, insulated, Test plug,
I N = I N terminal block with 500 mm cable,
gray 280-409 100 (4x25) 2.3 mm Ø
yellow 210-137 50
Push-in type wire jumper, Screwless end stop,
3 insulated, for DIN 35 rail,
I N 9 A, 6 mm wide
wire size 0.75 mm² gray 249-116 100 (4x25)
L = 60 mm 249-125 10 Screwless end stop,
L = 110 mm 249-126 10 for DIN 35 rail,
L = 250 mm 249-127 10 10 mm wide
gray 249-117 50 (2x25)
Certification organizations can be found in the overview on pages 622 and 623.
