830 Series

Pneumatic Toggle Clamps | Product Overview

Features: Applications: Also Available:
• Pneumatic version of Model 630 manual • Assembly See page MC-ACC-1
straight line action clamp • Welding for spindle accessories
• Sensor ready for round or T-slot style sensors See page MC-PSC-40
• Built-in flow restriction eliminates need for sensing options
for external flow controls

830
830-ME

Technical Information | Holding Capacities | Dimensions

Maximum Maximum Air
Model Holding Exerting Force Plunger Plunger Weight Bore Consumption † Port
Size
Size
Travel
Thread
Capacity @ 5bar [72PSI] dm [ft ]
3
3
830 [2500 lbf] [800 lbf] [0.75] 3/8-16 2,79kg [1.57] [0.029] 1/8 NPT
830-ME 11100 N 3582 N 19,1 M10 [6.14lb] 40 0,83 G-1/8
† Per double stroke at 5bar [72PSI]
Max Cylinder Pressure: 10bar [145psig] Sensor Accessories Item Number
Max Operating Temp: -10°C to 90°C [-14°F to 194°F] Round Reed Switch with Quick Disconnect 810169
Replacement Seal Kit: 810450-40-1-00 T-slot Reed Switch with Quick Disconnect 8EA-109-1
Replacement Clamp Assembly: 830-LC, 830-M-LC Quick Disconnect 2M Extension Cable CABL-010
Replacement Cylinder Assembly: 810CYL Quick Disconnect 5M Extension Cable CABL-013
* In no case should the inlet pressure be high enough to create 830
See Pneumatic Accessories section for more options
an exerting force that exceeds the clamp’s holding capacity.
See Technical Appendix Section for details.

830 3/8-16 [0.34] 830 1/8" NPT
830-ME M10 6XØ 8,6 830-ME G-1/8

[3.00]
76,2

AUXILIARY
UNCLAMP
[1.63] [0.50] [1.38] [1.62] PORT
41,4 12,7 35,1 41,1 [11.43] (830 ONLY)
290,3
[0.62]
[1.25] Ø 15,8 mm [INCH] mm [INCH]
31,8
[3.59]
[1.06] 91,1 THIRD ANGLE FIRST ANGLE
PROJECTION
PROJECTION
27,0

[1.97] [7.75] [0.43]
50,0 196,9 10,8
