81L Series

Pneumatic Power Clamps | Technical Specifications

Max. Clamping Air Consumption
Max. Holding Max. Added Load
Torque
Model Torque at 5 bar [72 psi] Weight per double stroke (at Position‚ “X”)
kg [lb]
at 5 bar [72 psi]
Nm [lb ft] g [oz]
Nm [lb ft] dm [ft ]
3
3
25 4,5 0,16 0,25 50
81L12-101..
[18.4] [3.3] [0.4] [0.01] [1.8]
20 4,5 0,17 0,25 50
81L12-141.. [14.8] [3.3] [0.4] [0.01] [1.8]
60 6,5 0,25 0,27 80
81L16-101..
[44] [4.8] [0.6] [0.01] [2.8]
40 7,0 0,27 0,26 80
81L16-141..
[29.5] [5.23] [0.6] [0.01] [2.8]
100 18 0,50 0,40 90
81L20-101..
[73.8] [13.3] [1.1] [0.02] [3.2]
80 17 0,52 0,35 90
81L20-141..
[59] [12.5] [1.2] [0.01] [3.2]
100 18 0,52 0,40 100
81L25-101..
[73.8] [13.3] [1.2] [0.02] [3.5]
80 17 0,54 0,35 100
81L25-141.. [59] [12.5] [1.25] [0.01] [3.5]

Dimensions and technical information are subject to change without notice PC-PPC-6
