Page 284 - Destaco - Clamping Technology

82L2G-2, 82L3.-2, 82L4.-2 Series

Pneumatic Power Clamps | Dimensions | Technical Specifications

H- Clamping Arms

Order no. Opening Opening Weight
for set of angle for 90ª - angle for 180ª B2 B4 B9 B10 B11 B12 B26 B34 B35 D2 D3 L4 L10 R1
Model Version - Version
H-clamping
arms max. max. [kg] +0,02 +0,1 +0,2 +0,1 H7 +0,1
82L3.-2.8... 8JG-363-1-01 105º 105º 0,52 105 45 6 20 79 20 69 47,1 59,1 6 7 20 12 55
82L4.-2.8... 8JG-364-1-01 105º 105º 0,77 110 45 6 20 84 20 78 57,1 72,1 6 7 22 15 58
Counter-Support B34
B10 B11
L10
View
Support without
bracket and screws D2 (2x) B12
B33 D3 (2x) B2 Pivot point

L30 B7 D5 (4x) Holding capacity L5 B26
L9 Deflection L31
M8 (4x) L4
L33 L32
±0,1
40 25 ±0,05 B32

B31
40 ±0,1 B30

* = Tolerance for distance to dowel holes +0,02 54
** = distance from pivot point
Holding Capacity
Fit for max. Deflection Weight B2 B7* B10 B11 B12 B26** B30** B31** B32**
Model
Model
[N] [mm] [kg] +0,1 +0,02 ~
BK-R25-82L25-1 82L2_ 914 0,2 0,4 93 25 20 62 20 42 55 31,5 11
BK-R25-82L32-1 82L3_ 660 0,16 0,5 105 20 20 79 20 44 52 28,5 9
BK-R25-82L40-1 82L4_ 2000 0,37 0,56 110 25 20 84 20 41 52 28,5 7,5

B33 B34 D2 D3 D5 L4 L5 L9 L10 L30 L31 L32 L33
Model
Ø H7 Ø Ø +0,1 +0,1 -0,1
BK-R25-82L25-1 35 90 4 6,5 5,5 20 45 18 12 4,95 27,9 50,9 106
BK-R25-82L32-1 46 105 6 7 5,5 20 45 20 12 7,85 35,7 59 106
BK-R25-82L40-1 40 110 6 7 6,6 22 45 20 15 9,85 39,7 66 108

PC-PPC-21 Dimensions and technical information are subject to change without notice
