Pipeline Construction Permanent
Automatic Self-Cleaning Strainers Strainer Cast Media

2596 10”-16”

Eaton’s Model 2596 Automatic Self-Cleaning

Cast Pipeline Strainers are available in 10”,
12”, 14” and 16” sizes. The Model 2596 is
recognized across industries for its continuous
flow, simplified maintenance, and worry-free

operation. Model 2596 10”

FeaTures / BeneFiTs The Eaton Model 2596 The Model 2596 features the
Automatic Self-Cleaning idL™ shaft seal that positively
3
• Flow rates up to 6500 gpm (1476 m /hr) Strainer is designed for the prevents leakage from the
• A broad selection of screen options continuous removal of backwash shaft at the top of
entrained solids from liquids
the strainer. This unique quad
• Automatic backwashing for operator-free service in pipeline systems. seal keeps the exterior of the
and minimal backwash effluent strainer dry and prevents
• Exclusive idL™ Seal for leak free service With an automated control external leakage or weeping of
system monitoring the strainer
• Unitized modular assembly for easy maintenance operation, cleaning is accom- the process media down the
sides of the strainer.
• Cast ductile iron construction plished by an integral back-
wash system. A small portion To simplify maintenance the
of the screen element is Model 2596 features a unitized
isolated and cleaned by modular assembly. The motor,
reverse flow while the gear reducer, and the internal
remaining screen area operating mechanism are all
continues to strain—providing housed within the strainer
uninterrupted flow. This effi- cover and lift off as a unit. This
cient design uses only a small makes all components easily
amount of the liquid being accessible and reduces associ-
strained to carry debris away ated maintenance costs.
from the strainer element.
