Page 56 - ENGINEERING

INFRINGEMENT
SL. SIGNAL DISTANCE
NO STATION NO SIGNAL DESCRIPTION Remarks
LH RH

SC-WADI SECTION

35 SNF S43 CL-1 Starter 2 Gantry
36 SNF S44 UP Main line starter 2.1 Gantry
37 SNF S45 UP Advance Starter 2.8 4.61
38 HFZ S30 UP Home signal 2.9
39 HFZ S26 UP Common loop starter 2.75 2.36
40 HFZ S27 UP Loop line starter 2.7
41 HFZ S28 UP Main line starter 2.65 3
42 HFZ S25 UP Advance Starter 2.9
43 HFZ S1 Down Home siganl 2.9
44 HFZ S3 Down Main line Starter 2.4 2.45
45 HFZ S4 Down 2nd loop starter 2.4 2.4
46 HFZ S5 Down Loop Line Starter 2.75
47 HFZ S6 Down Advance Starter 2.65
48 HFZ SH 22 SHUNT 2.65
49 HFZ SH 48 SHUNT 2.9
50 HFZ SH 23 SHUNT 2.55
51 HFZ SH 24 SHUNT 2.75
52 LPI S3 UP mainline starter 2.4 2.54
53 LPI S4 UP Loop line starter 2.85
54 LPI S5 UP Common loop starter-2 2.61 2.7
55 LPI S13 UP Common loop starter-1 2.54 2.6
56 LPI S44 Down RD-6 starter 3,0
57 LPI S45 Down RD-5 starter 2.65 2.64
58 LPI S47 Down loop line starter 2.5
59 LPI S48 Down Main line Starter 2.8 4.2
60 LPI S43 Down Advance Starter 2.85
61 TLPR S20 UP Home signal 2.40
62 TLPR S9/2D DN distant 2.75
63 TLPR S2 ID DN Inner distant 2.45
64 TLPR S2 DN home 2.60
65 TLPR S6/50D DN LSS/D 2.52
66 TLPR S1D B/L Dist 2.45
67 TLPR S1 B/L Home 2.85
68 TLPR S18 LSS B/L 2.95
69 TLPR S14 ID UP ID 2.6
70 NPL S50 ID UP Inner Dist 2.65
71 NPL S50 UP Home 2.5
72 NPL S46 UP Common loop starter 2.75
73 NPL S47 UP Loop line starter 2.5
74 NPL S48 UP Main line starter 2.35
75 NPL S3 Down Main line Starter 2.38
Down Common Loop
76 NPL S4 2.91
starter
77 NPL S8 Down Advance Starter 2.65
78 NPL SH12 SHUNT 2.42
79 NPL SH37 SHUNT 2.72
80 NPL SH38 SHUNT 2.49
