Pivoting Shackle Brackets

• Complies with customs regulations, with welded back plate, zinc-pla-
ted
• For round eyelets Ø 36 and 40 mm and oval eyelets 42 x 22 mm
Technical Data
Art.-No. Height Rod Ø Hole interval
3402 4 37 37 mm 4 mm 30 mm
3402 4 45 45 mm 4 mm 30 mm
3402 4 55 55 mm 4 mm 30 mm

Article No. Article Description QTY
3402 4 37 PIVOTING SHACKLE ZI 37MM 50
3402 4 45 PIVOTING SHACKLE ZI 45MM 50
3402 4 55 PIVOTING SHACKLE ZI 55MM 50

Strap Staples

• With straight plate, zinc-plated
• For eyelets 38 x 8 mm

Technical Data
Art.-No. Height Rod Ø Hole interval
3402 6 15 15 mm 4 mm 51 mm
3402 6 20 20 mm 4 mm 51 mm
3402 6 25 25 mm 4 mm 51 mm
3402 6 30 30 mm 4 mm 51 mm

Article No. Article Description QTY
3402 6 15 STRAP BRACKET ST.PLATE ZI 15MM 100
3402 6 20 STRAP BRACKET ST.PLATE ZI 20MM 100
3402 6 25 STRAP BRACKET ST.PLATE ZI 25MM 100
3402 6 30 STRAP BRACKET ST.PLATE ZI 30MM 100

Small Strap Staples

• With even plate, zinc-plated
• For eyelets 27 x 8 mm

Technical Data
Art.-No. Height Rod -Ø Hole distance
3402 7 12 12 mm 4 mm 34 mm
3402 7 16 16 mm 4 mm 34 mm

Article No. Article Description QTY
3402 7 12 SMALL STRAP BRACKET ZI 12MM 100
3402 7 16 SMALL STRAP BRACKET ZI 16MM 100
