EOS 90455-A-PHY-0012-Covers assembly
REAR VIEW
11. Profile side back panels – This set of panels (a & c) cover most of the profile
side area and provides easy mounting and dismounting for service. Each
panel is attached with quarter-turn X6 Dzus bolts
12. Face side back panels – This set of panels (d & b) cover most of the face
side area and provides easy mounting and dismounting for service. Each
panel is attached with quarter-turn X6 Dzus bolts
