5.4 GS AREA OBSERVATIONS

Element Condition Observed Dimension

Grade Transition Elevation differential requiring 134 linear meters

Lateral Support stabilization Area would benefit from Height: 1, 100mm Total

Required retaining structure Drystack retaining face area: 147.4 m 2

Intervention
◄ wall consideration ►

6. ENGINEERING SOLUTION: DEMONSTRATION SCOPE

From our understanding of civil rehabilitation best practices and SANS 1200 standards, we would propose the

following approach for your consideration. We recognise that your team may have specific methodologies and
quality standards, and we welcome the opportunity to align our approach accordingly.

2
6.1 ROAD REHABILITATION WORKS (6,000 m )

Proposed Scope Summary:

The rehabilitation would involve full-depth reconstruction incorporating:

• Site preparation and existing surface removal

• Subgrade remediation and unsuitable material replacement where encountered

• Imported engineered fill material (approved source with certifications)

• Geotextile separation layer for base reinforcement

• Mechanical compaction to 95% Modified AASHTO density

• Cement stabilisation (3-5%) for heavy traffic zones

• Quality testing and dimensional verification throughout

Technical Specifications:

Parameter Proposed Standard Unit Rate

Total Area 6,000 m 2 R85.00/
m 2
Base Compaction 95% Modified AASHTO Included in rate
2
Geotextile 200g/m non-woven separation Included in rate

Cement Stabilization fabric 3-5% (heavy traffic zones) Included in rate

Standards Compliance SANS 1200D (Earthworks) Included in rate

Total Investment R510,000.00 + VAT

◄ ►
