Reference Guide                                                         Fire Strategy



               Pipes of aluminium alloy, fibre cement or UPVC with a maximum internal diameter of 160mm

               may be sleeved with a non-combustible material for a distance of not less than 1,000mm
               either side of the fire resisting element.

               1.5.21  Fire and smoke dampers


               Fire dampers are to be provided within any ductwork at the point which it penetrates a fire

               separating element. All fire dampers and their frames should be tested to BS EN 1366-2 and
               be classified to BS EN 13501-3. They should have an E classification equal to or greater

               than the wall/floor through which they pass.

               Fire dampers activated only by fusible links are not suitable for protecting escape routes. In
               such instances an ES classified fire and smoke damper which is activated by a fire and

               smoke detector shall be used. All other dampers should be fire rated E60.

               In this instance ES 60 classified fire and smoke dampers activated by smoke detection are
               required in all ductwork passing through a protected lobby and/or protected stair. It is

               however noted services are not permitted to run through or be accessed from the fire fighting
               stair.


               Detailed requirements are specified in Section 6 of BS 9991, where the M& E consultant/
               contractor is unsure of the requirements of the proposed fire and/or smoke dampers, it is
               recommended a workshop is arranged with a qualified fire engineer to review the provisions.


               It should be ensured that unobstructed access is provided to all dampers via an access
               hatch located on the appropriate side of the damper to allow routine maintenance.

               1.6  B4 – External Fire Spread



               Approved Document B provides guidance on separation between buildings and boundaries.
               The intent of this guidance is to reduce the potential for fire spread between buildings via

               both direct flame impingement and radiant heat.

               External fire spread conditions should be assessed on a case-by-case basis as these
               depend on a number of factors including, though not limited to, the presence of adjacent

               buildings and the site boundary.
