REMOTE HYDRAULIC TOOLS

TPU-1500H REMOTE OPERATED HYDRAULIC TOOL

15 TON OUTPUT FORCE

• Compatible with industry standard 15 ton “P” dies as well as standard
12 ton “U” dies with the PU-15 adapter (pg. 20)

• 1.97 in. jaw opening, 1.67 in. jaw opening with “U” die adapter

• 15 ton output with any 10,000 psi hydraulic pump

• Compression lugs and splices are UL Listed and CSA certified
when installed with specified die set

• Includes durable high impact carrying case For use with: BCU, BBCU, BLU, BBLU, BBLZ, TLU, LL,
LLR, and LLN style copper connectors;
CAPACITY: 8 AWG - 1500 MCM Copper Lugs/Splices
8 AWG - 1250 MCM Aluminum Lugs/Splices BCUA, BLUA, DBTBF, KO, KD, KN, PIK, PSK, PS, PSS,
PSKS, KBO, KKBO, KBD, KKBD, FKLA, FSLA, FULA style
LENGTH: 11.8 in. WEIGHT: 15.4 lbs.
aluminum connectors

TPU-6FTH DIELESS REMOTE OPERATED HYDRAULIC TOOL

6 TON OUTPUT FORCE

• Flip top design with pull pin locking mechanism For use with: BCU, BBCU, BLU,
• Accepts larger connectors up to 750 MCM BBLU and BBLZ style copper connectors;
• Dieless installation system utilizes four indentors to make crimp,
eliminates the need to purchase and maintain dies BCUA and BLUA style aluminum connectors
• UL Listed and CSA Certified range taking crimp connections when (NOT UL listed or CSA certified with this tool)
used with Penn Union copper color-coded lugs and splices
(6 AWG - 750 MCM)
• Includes durable high impact carrying case

CAPACITY: 8 AWG - 750 MCM Aluminum & Copper Lugs/Splices
LENGTH: 11.0 in. WEIGHT: 6.6 lbs.

12
