produces a mirrored image which is reflected about the vertical
axis. The default setting for mirror is False.

o Negative: an option for output negative (True) or not
(False). If True is selected in the Negative dropdown list, the
page produced by the device is in negative.

™ Margin

o Left/Top Margin: You can set the margins by typing values
into the appropriate text boxes. Any margins you specify are
added to values set within the job. When you specify the left
margin, the right margin is calculated automatically, based on
the total width of the media and the size of the image. If you
wish, you can specify a negative value for any margin. For
example, a –1.0 inch left margin would clip 1 inch off the left
hand side of the page. You may change the unit under RIP
Setup>Misc Tab.

o Alignment: The options in Alignment dropdown list allow you
to specify how to align the image with the output media. The
options include: No Alignment, Horizontal Auto Center,
Vertical Auto Center, Left Alignment, Center Alignment,
Right Alignment, Top Alignment and Bottom Alignment.

™ Ganging

To select a parameter used to control bitmap page ganging.

The basic principles of Cron_pci device driver bitmap page ganging: As
the Cron_pci imagesetter film may be bigger than your desired output
page size, Cron_pci device driver provides auto ganging function so
that you can use the film more efficiently. Generally speaking, if the
output parameter setting of one or more bitmap of the requested
printing job are compatible (for example, parameters such as the
Device Model, Media Size, Margin, Cut Mode, Ganging, Mirror,
Negative, Exposure are all consistent), and the currently selected
media size can accommodate such bitmaps (bitmap does not overlap,
and there are needed spacing among the bitmaps), then Cron_pci
device driver can combine these bitmap page to a big page and output.

¾ Selecting the ganging option may result in Cron_pci device driver’s
waiting for enough pages to be combined into a surface before
actually output the surface when the surface is deemed full. And in
Any Job ganging mode, the surface will not be output even if all
the jobs have been interpreted, unless the surface is full. If you

17
