Mitsubishi PISTONS COMPLEMENTARY PARTS

6G75 as in Eclipse/Pajero
OEM Engine details 3,8 Ltr 24V Engine code:6G75 • Displacement:3828 cc • Valves:24 • Comp. Ratio:10,5:1 • Head cc’s:N/A • Gasket thickness:N/A • Rod Length:153,50
Bore:95,00 • Stroke:90,00 • Block Ht:228,00
Kit Part # Bore (mm) Over size Comp. Ht. Dome/Dish cc’s Deck Clr. Comp. Ratio Pin Ø Ring # Gram Foot Notes Head Gasket Connecting Rods Crank
KE251M95 95,00 Std. 29,00 -2,5 0,50- 10,3:1 22 9500XX 400 M,R - - - MITSUBISHI
KE251M955 95,50 0,50 29,00 -2,5 0,50- 10,3:1 22 9550XX 406 M,R - - -
KE251M96 96,00 1,00 29,00 -2,5 0,50- 10,3:1 22 9600XX 410 M,R - - -
Bearings Rod Main Thrust Head Stud Kit Rod Bolts Main Stud Kit
ACL - - - - - -
KING - - -
Nissan

CA18DET as in Silvia
OEM Engine details 1,8 Ltr 16V Engine code:CA18DET • Displacement:1809 cc • Valves:16 • Comp. Ratio:8,0:1 • Head cc’s:51,00 • Gasket thickness:1,50 • Rod Length:132,90
Bore:83,00 • Stroke:83,60 • Block Ht:204,75 NISSAN
Kit Part # Bore (mm) Over size Comp. Ht. Dome/Dish cc’s Deck Clr. Comp. Ratio Pin Ø Ring # Gram Foot Notes Head Gasket Connecting Rods Crank
K630M83 83,00 Std. 29,75 -0,5 FT 0,30- 8,5:1 20 8300XX 303 1,F,M,Q W6582 033CO14133 / R-NIS-001H -
K630M835 83,50 0,50 29,75 -0,5 FT 0,30- 8,5:1 20 8350XX 309 1,F,Q W6582 033CO14133 / R-NIS-001H -
K630M84 84,00 1,00 29,75 -0,5 FT 0,30- 8,5:1 20 8400XX 312 1,F,Q W6582 033CO14133 / R-NIS-001H -
Kit Part # Bore (mm) Over size Comp. Ht. Dome/Dish cc’s Deck Clr. Comp. Ratio Pin Ø Ring # Gram Foot Notes Head Gasket Connecting Rods Crank
302299 83,00 Std. 30,00 -0,5 FT 0,05- 8,5:1 20 JG1004-3268 293 PS,S,T W6582 033CO14133 / R-NIS-001H -
302300 83,50 0,50 30,00 -0,5 FT 0,05- 8,5:1 20 JG1004-3287 295 PS,S,T W6582 033CO14133 / R-NIS-001H -
302301 84,00 1,00 30,00 -0,5 FT 0,05- 8,5:1 20 JG1004-3307 297 PS,S,T W6582 033CO14133 / R-NIS-001H -
Bearings Rod Main Thrust Head Stud Kit Rod Bolts Main Stud Kit
ACL 4B1630H(HX/0,025/0,25/0,50) 5M1633H(HX/0,025/0,25/0,50) - 202-4702 - -
KING CR 407XP MB5232XP -
FJ20 as in Silvia
OEM Engine details 2,0 Ltr 16V Engine code:FJ20ET • Displacement:1990 cc • Valves:16 • Comp. Ratio:9,0:1 • Head cc’s:49,50 • Gasket thickness:1,30 • Rod Length:140,00
Bore:89,00 • Stroke:80,00 • Block Ht:212,00
Kit Part # Bore (mm) Over size Comp. Ht. Dome/Dish cc’s Deck Clr. Comp. Ratio Pin Ø Ring # Gram Foot Notes Head Gasket Connecting Rods Crank
K574M895 89,50 0,50 32,18 -16,7 0,18 8,0:1 22 8950XX 383 1,M W6311 - -
K574M90 90,00 1,00 32,18 -16,7 0,18 8,0:1 22 9000XX 386 1,M W6311 - -
C/R with 1,00 mm head gasket
Kit Part # Bore (mm) Over size Comp. Ht. Dome/Dish cc’s Deck Clr. Comp. Ratio Pin Ø Ring # Gram Foot Notes Head Gasket Connecting Rods Crank
317882 89,00 Std. 32,00 -10 0 8,5:1 22 JG1004-3504 327 M,S,T C4326-040 - -
317883 89,50 0,50 32,00 -10,7 0 8,5:1 22 JG1004-3524 330 M,S,T C4326-040 - -
317884 90,00 1,00 32,00 -11,4 0 8,5:1 22 JG1004-3543 333 M,S,T C4326-040 - -
317885 89,00 Std. 32,00 -2,2 0 9,5:1 22 JG1004-3504 343 M,S,T C4326-040 - -
317886 89,50 0,50 32,00 -2,8 0 9,5:1 22 JG1004-3524 346 M,S,T C4326-040 - -
317887 90,00 1,00 32,00 -3,4 0 9,5:1 22 JG1004-3543 349 M,S,T C4326-040 -

Bearings Rod Main Thrust Head Stud Kit Rod Bolts Main Stud Kit
ACL - - - - - -
KING - - -

134 **When exceeding 2 BAR boost and/or 500HP(4 Cylinder), please inquire for needed/available pin upgrades!! For 200+HP per cilinder custom part is adviced!!** Custom Capabilities: see page 24 - Foot Notes: see page 226 for description - Instructions & Terminology: see pages 356 135
