Page 237 - CATALOGUE (32)

215 SMS1517 SMS2021 216

PALETTE IN SMS 15 12.4 19.5 17 PALETTE IN SMS

17

Ⅲ Ⅲ 21

FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION
SMS SURFACE MOUNTED 1517 1000mmX17.2mmX15.5mm AP ALUMINUM PROFILE RD RECESSED SMS SURFACE MOUNTED 2021 1000mmX21mmX19.5mm AP ALUMINUM PROFILE RD RECESSED
SYSTEM
PD PC DIFFUSER SYSTEM PD PC DIFFUSER
ED END CAPS (PLASTIC) EDP END CAPS (PLASTIC)
CL CLIPS (PLASTIC) EDS END CAPS (SPRING CLIPS)
EXAMPLE: SMS1517-1000mmX17.2mmX15.5mm-RD EXAMPLE: SMS2021-1000mmX21mmX19.5mm-RD
RMS2020A SMS4135

12.5 33.6
19.4
19.4 41.5
11.4 17
11.4
19.4
19.4
35
Ⅲ Ⅲ

FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION
SMS SURFACE MOUNTED 2020A 1000mmX19.4mmX13.4mm AP ALUMINUM PROFILE RD RECESSED SMS SURFACE MOUNTED 4135 1000mmX35mmX41mm AP ALUMINUM PROFILE RD RECESSED
SYSTEM SYSTEM
PD PC DIFFUSER PD PC DIFFUSER
ED END CAPS (PLASTIC) ED END CAPS (PLASTIC)
BR BRACKET BR BRACKET
EXAMPLE: SMS2020A-1000mmX19.4mmX19.4mm-RD EXAMPLE: SMS4135-1000mmX35mmX41mm-RD
SMS2020B RMS3542

42
19.4

12.7 33.6
20 35
17

19.4

Ⅲ Ⅲ

FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION
SMS SURFACE MOUNTED 2020B 1000mmX20mmX19.4mm AP ALUMINUM PROFILE RD RECESSED SMS SURFACE MOUNTED 3542 1000mmX42mmX35mm AP ALUMINUM PROFILE RD RECESSED
SYSTEM SYSTEM
PD PC DIFFUSER PD PC DIFFUSER
ED END CAPS (PLASTIC) ED END CAPS (PLASTIC)
BR BRACKET BR BRACKET
EXAMPLE: SMS1216-1000mmX16mmX12mm-RD EXAMPLE: SMS3542-1000mmX42mmX35mm-RD
