Diagnosis - Diagnosis-fault diagnosis of electronic and electrical parts DI - 163
Check if the result is ok? IN
Yes>go to Step 5.
NO>repair or replace the wiper combination switch. DI
5. Check the scrubbing motor
EG
a. Check the scrubbing function
● Pour the water into the windshield washer equipped with
TR
scrubbing motor.
● Connect the positive terminal (+) of the battery to the No.
1 terminal of the wiper assembly, and the negative terminal AX
(-) to No. 2 terminal, and then check whether the water can
flow out from the windshield washer.
FR
Check if the result is ok? ST
Yes> Repair or replace the harness.
No> Repair or replace the scrubbing motor. BR
