Circuit- Guide to the circuit
Note:
S/N Name Description
System
10 Summary to describe the system or the working principle of the system.
summarization
It is used to describe the numeral value or working state of electric element; for
11 Service guide
reference during troubleshooting.
It is used to indicate the page of wire harness needs to be referred (the position of the
12 Part position
electric element on vehicle and the direction of the wire harness)
It is used to indicate the reference wire page of the wire to which insert part connecting
Insert part of wire
13 to each other belong (the wire with female connector is in the front and the wire with
harness
male connector is in the rear).
Grounding It is a reference page to indicate the connection point of return circuit of electric
14
(earth) element and metal body of vehicle.
