61-38
Circuit-System circuit diagram

: Part position

Reference wire Reference wire Reference wire
S/N S/N S/N
harness harness harness
B013 Body wire B050 Body wire C037 Chassis wire
B022 Body wire C004 Chassis wire C038 Chassis wire

B029 Body wire C007 Chassis wire C039 Chassis wire
B032 Body wire C011 Chassis wire C040 Chassis wire
B033 Body wire C015 Chassis wire C048 Chassis wire
B034 Body wire C027 Chassis wire C051 Chassis wire
B037 Body wire C032 Chassis wire L002 Left floor wire
B046 Body wire C033 Chassis wire

: Insert parts between wire harnesses

S/N S/N Reference wire harness (position of the insert parts)
B103 C101 Body wire and chassis wire (middle of the first cross member of frame)
C103 B107 Body wire and chassis wire (middle of the first cross member of frame)
C105 B105 Body wire and chassis wire (middle of the first cross member of frame)
C106 B104 Body wire and chassis wire (middle of the first cross member of frame)
L101 B110 Body wire and left floor wire (left and below of meter, at the position of clutch pedal)

: Grounding

S/N Grounding position
A204 Left side of instrument panel is grounded
B205 Right side of front panel is grounded
61 B206 Right side of instrument panel is grounded
B207 Right side of front panel is grounded
B208 Left side of instrument panel is grounded
B209 Right side of instrument panel is grounded
C211 Negative pole of battery is grounded to frame

C238 Chassis wire is grounded
