Page 210 - Workshop Manual - Aumark (BJ1051)
P. 210
04-66
Diagnosis-ABS system
3. Checking for ABS malfunction indicator light circuit open
(a) Use a multimeter to measure voltage to
ground of connector pin 14 of
combination meter B032.
Voltage: battery voltage
04
Are check results normal?
Yes > Repair line open between connector pin 14 of combination meter B032 and connector pin 15
of ABS control unit B013.
No > Replace combination meter assembly.
Page 210
