31A-10
Transmission (646b/651b)-gearshift flexible axle and gear selecting flexible axle

13. Connect the transmission
(a). Install the gearshift flexible axle and the gear
selecting flexible axle on the flexible axle frame
assembly.

Notice:
• Don’t distort the core of flexible axle.
• Don’t make the flexible axle have sharp turn.
• Don’t hold the dust cover with hands during the
operation so as to avoid damaging the internal
structures.
• Make sure that all the gears are clear and
correctafter assembling the control mechanism
assembly,; the gears can be shifted easily and
flexibly without clamping or interference.

(b). Install the gearshift flexible axle and the gear
selecting flexible axle on the transmission gearshift
arm and gear selecting arm respectively.
