31A-17
Transmission (646b/651b)-transmission assembly
(c). Measure the thrust washer thickness of the
fourth-shifting gear.
Model Standard Limit
646B 6 mm 5.95 mm
651B 6 mm 5.95 mm
(d). Remove the fourth-shifting gear attachment and the
needle bearing from the secondary axle.
6. Remove the third-shifting and fourth-shifting
synchronizers.
(a). Remove the third-shifting and fourth-shifting
synchronizer retainer rings.
31A
