Silentblocs and Bushings

KL-0040-2228
KL-0040-2228
Pressure Gauge for KL-0040-2200,
with 3/8“ NPT Connection Thread

Suitable for KL-0215-37 etc.
The pressure gauge can be screw-connected between the hydraulic pump and hose
so as to allow the hydraulic pressure to be monitored during operation.
The pressure gauge features an additional tonne scale that is specifically adapted to
our hydraulic cylinder KL-0040-2200.

Scope of Delivery:
KL-0040-2228 Pressure Gauge for KL-0040-2200, with 3/8“ NPT Connection Thread
Technical Data: Part No. Description Qty
Measuring Range: 1,000bar KL-0040-2229 Pressure Gauge for KL-0040-2200, with 1/4" NPT Connection Thread 1
Pressure gauge Ø: 71mm KL-0040-2520 Adaptor 3/8" NPT to 1/4" NPT 1
Connection thread: 3/8“ NPT KL-0040-2524 Adaptor 1/4" NPT to 3/8" NPT 1

KL-0040-2290
KL-0040-2290
Safety Belt for Hydraulic Cylinder (10t)

4 By using the safety belt KL-0040-2290 on the vehicle and on the hydraulic cylinder
KL-0040-2200, the latter is prevented from falling.

Accessories for the KL-0040-2800 Hydraulic Cylinder (28t)
KL-0040-288
KL-0040-288
Retaining Device
for Hydraulic Cylinder KL-0040-2800

The KL-0040-288 retaining device is used in conjunction with a transmission jack
(plunger Ø of 30mm), thus enabling easy and trouble-free working with all those
GEDORE Automotive tools that are driven by the KL-0040-2800 hydraulic cylinder.

Scope of Delivery: KL-0040-288 Retaining Device for Hydr. Cyl. KL-0040-2800
Part No. Description Qty
KL-0040-2580 A Retaining Device without Clamp Ring 1
Technical Data: KL-0040-2881 Clamp Ring for Hydraulic Cylinder 1
Retaining Ø: 30mm KL-0040-2882 Adaptor Ring 1

KL-0040-2810
KL-0040-2810
Pressure Spindle, M24

Technical Data:
Length: 405mm
Maximum load capacity: 28t

KL-0040-2812
KL-0040-2812
Pull Spindle, M24, with Clamping Nut

Suitable for hydraulic cylinder KL-0040-2800.

Scope of Delivery: KL-0040-2812 Pull Spindle, M24, with Clamping Nut
Technical Data: Part No. Description Qty
Length: 590mm KL-0040-2812-1 Pull Spindle, M24x590mm 1
Maximum load capacity: 28t KL-0040-2812-3 Clamping Nut, M24/Ø 40mm 1
