VW-Audi

KL-0214-20 KL-0214-20
Pulling Device with Hydraulic Cylinder,
VW Touareg

Designed for suspension strut mount silentblocs as found on VW Touareg front
KL-0214-200
axle wishbones (with solid silentbloc for bore Ø of 46mm).
Enables the quick and safe removal and replacement of suspension strut mount
silentblocs without the need for removing the wishbone from the vehicle.

Scope of Delivery:
KL-0214-20 Pulling Device with Hydraulic Cylinder, VW Touareg
Part No. Description Qty
KL-0040-2500 Hydraulic Cylinder, 17t 1
KL-0040-2552 Adaptor, M42x2 to Ø 30mm 1
KL-0214-200 Pulling Device without Hydraulic Cylinder 1
Scope of Delivery:
KL-0214-200 Pulling Device without Hydraulic Cylinder, VW Touareg
Part No. Description Qty
KL-0040-2543-5 Pull Spindle, M14 (Length 550mm) 1
KL-0040-2543-2 Shoulder Nut, M14 1
KL-0214-2005 Support Sleeve 1
KL-0214-2006 Support Sleeve 1 4
KL-0214-2007 Pressure Piece 1

KL-0214-21 KL-0214-21

Pulling Device with Hydraulic Cylinder,
VW Touareg

Designed for suspension strut mount silentblocs as found on VW Touareg front
axle wishbones (split- or solid-type silentbloc, for bore Ø of 46mm).
Enables the quick and safe removal and replacement of suspension strut mount
KL-0214-210
silentblocs without the need for removing the wishbone from the vehicle.
Scope of Delivery:
KL-0214-21 Pulling Device with Hydraulic Cylinder, VW Touareg
Part No. Description Qty
KL-0040-2500 Hydraulic Cylinder,17t 1
KL-0040-2552 Adaptor, M42x2 to Ø 30mm 1
KL-0214-210 Pulling Device without Hydraulic Cylinder 1
Scope of Delivery:
KL-0214-210 Pulling Device without Hydraulic Cylinder, VW Touareg
Part No. Description Qty
KL-0040-2543-5 Pull Spindle, M14 (Length 550mm) 1
KL-0040-2543-2 Shoulder Nut, M14 1
KL-0214-2001 Conical Sleeve, Ø 46mm 1
KL-0214-2002 Spring-Loaded Pressure Piece, Ø 46mm 1
KL-0214-2003 Centring Ring, Ø 46mm 1
KL-0214-2004 Centring Ring, Ø 46mm 1
KL-0214-2005 Support Sleeve 1
KL-0214-2006 Support Sleeve 1
KL-0214-2007 Pressure Piece 1
