Mercedes

KL-0356-11 KL-0356-11
Pulling Device with Hydraulic Cylinder,
Silentbloc, Mercedes

Suitable for Mercedes W202 (C-Class) and W208 (CLK) rear axle subframe.
KL-0356-110
The pulling device KL-0356-11 allows for the fast removal and replacement of all the
silentblocs found on the rear axle subframe (including differential mounting bushes).
Dismantling the rear axle subframe is not necessary. KL-0356-111

Advantages:
• Fast - Large time savings of up to 3 hours.
• Safe - No hammer, chisel or similar tools needed.
• Universal - Hydraulic Cylinder KL-0040-2500 can be used with many other GEDORE
Automotive tools.

Scope of Delivery:
KL-0356-11 Pulling Device with Hydraulic Cylinder, Silentbloc, Mercedes
Part No. Description Qty
KL-0040-2500 Hydraulic Cylinder, 17t 1 4
KL-0040-2552 Adaptor, M42x2 to Ø 30mm 1
KL-0356-110 Pulling Device without Hydraulic Cylinder, Silentbloc 1

Scope of Delivery:
KL-0356-110 Pulling Device without Hydraulic Cylinder, Silentbloc, Mercedes
Part No. Description Qty
KL-0040-2542-2 Shoulder Nut, M12 1
KL-0356-111 Set of Sleeves 1
KL-0039-1912-1 Pull Spindle, M12 1

Scope of Delivery:
KL-0356-111 Set of Sleeves, Mercedes
Part No. Description Qty
KL-0356-1101 Support Sleeve 1
KL-0356-0005 Adaptor Ring 1
KL-0356-1102 Pressure Sleeve 1
KL-0356-1103 Thrust Piece 1
KL-0356-1104 Thrust Piece 1
KL-0356-1105 Support Plate 1
KL-0356-1106 Thrust Piece 1
KL-0356-1107 Support Sleeve 1
KL-0356-1108 Support Sleeve 1
KL-0356-1109 Pressure Sleeve 1
KL-0355-2002 Support Ring 1

Copyright GEDORE Automotive GmbH, Germany (183) 4-47
