DUAL WHEEL DOLLY

Designed for transporting agricultural and truck wheels or tyres around the workshop.

FEATURES

 Handles wheels and tyres up to 500kg in weight.

 Safety support arm keeps wheel or tyre safely on the trolley.

 Back upright support arms double as jack handle and help with
manoeuvrability.

 Wide rollers for safer handling of wheels and alignment of
wheel studs.

 Large swivel wheels for easy manoeuvrability.

Width between
Part Number
Width between
Roller
WHEEL HANDLING FEATURES Working Load roller arms closed roller arms open length Overall Height
Limit
(Safety arm)
LT500DWD
500kg
2,100mm
1,400mm
850mm
700mm
WHEEL DOLLY
 Load levelling rear wheel to allow alignment of drum to brake shoes and wheel studs, so
reducing the threat of thread damage.
 Rear caster wheels and fixed front wheels provide positive steering and effortless
manoeuvring.
 3 Position adjusting tubular lifting arms.
 Each arm has rollers which allow wheel rotation
for alignment.
 Foot operated hydraulic jack
 Foot pedal can be folded up for storage and to
prevent operator injury.
 Heavy duty chain for securing wheels.
 Long handled release knob provides
convenience of work when the operator is
standing.
 Nut and Stud Tray

See Also: Ritch Wheel Handling on Page 36

Part Working Max Width of Width of Lifting arms Lifting arms Overall Overall Overall Net
Number Load Limit Lift roller arms roller arms lowered raised Height Width Depth Weight
closed open Height Height
777B 600kg 300mm 530mm 762mm 100mm 300mm 815mm 970mm 965mm 120kg
