Truck Engine Muffler Application
TRUCK ENGINE APPLICATION Engine Make & 3126B Engine 175 Inlet Body Outlet Inlet Body Outlet Backpressure 3 M110479 Notes

Muffler Dimensions
inches
Exhaust System
inches of Muffler
mm
Configuration
Hg
H 2 0 Style & Part No.
H.P.
Model

102
102
279
4.0
4.0
31
2.3
11.0
11.0

3
M111024 Outlet has down spout

4.0
2.1

28

11.0
279
102

1.4

3
M120235 OE replacement

19
5.0
5.0
127 254x381 127
102
3
38
M110479
11.0
2.8
4.0
4.0
279
102
3126B 190 4.0 10x15 4.0 102 279 102 2.1 29 3 M110674 Band clamp on inlet
4.0 11.0 4.0 102 279 102 2.6 35 3 M110674 Band clamp on inlet
4.0 11.0 102 279 2.5 34 3 M111024 Outlet has down spout
5.0 10x15 5.0 127 254x381 127 1.7 23 3 M120235 OE replacement
3126B 210 to 230 4.0 11.0 4.0 102 279 102 2.6 35 3 M110479
4.0 11.0 4.0 102 279 102 2.4 32 3 M110674 Band clamp on inlet
4.0 11.0 102 279 2.3 31 3 M111024 Outlet has down spout
5.0 10x15 5.0 127 254x381 127 1.5 21 3 M120235 OE replacement
3126B 250 4.0 11.0 4.0 102 279 102 2.9 39 3 M110674 Band clamp on inlet
4.0 11.0 102 279 2.8 38 3 M111024 Outlet has down spout
5.0 10x15 5.0 127 254x381 127 1.8 25 3 M120235 OE replacement
3126B 275 4.0 11.0 4.0 102 279 102 2.8 39 3 M110674 Band clamp on inlet
4.0 11.0 102 279 2.7 37 3 M111024 Outlet has down spout
5.0 10x15 5.0 127 254x381 127 1.8 25 3 M120235 OE replacement
3126B 300 5.0 10x15 5.0 127 254x381 127 2.0 27 3 M120235 OE replacement
3126B 330 5.0 10x15 5.0 127 254x381 127 2.5 34 3 M120235 OE replacement
C-10 305 to 370 5.0 10x15 5.0 127 254x381 127 2.6 36 3 M120235 OE replacement
Cummins
ISM 310 to 350 4.0 8.5 4.0 102 216 102 1.2 17 1 M085171
4.0 9.0 5.0 102 229 127 1.7 24 1 M090781
5.0 9.0 5.0 127 229 127 1.5 20 1 M090074
5.0 9.0 5.0 127 229 127 0.8 11 1 M090535 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 0.8 11 1 M100463 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 1.6 21 1 M100465 Best value, most popular
5.0 10.0 5.0 127 254 127 1.6 22 1 M100580 OE replacement
5.0 10.0 5.0 127 254 127 1.8 24 1 M100807 60” (1524mm) Long Body
5.0 10.0 5.0 127 254 127 1.3 18 1 M100944 OE replacement for higher HP
5.0 10.0 5.0 127 254 127 1.6 22 1 M101158 Silent Partner Stainless
5.0 10.0 5.0 127 254 127 1.6 22 1 M101181 Silent Partner Aluminized
5.0 10.0 5.0 127 254 127 1.6 22 1 M101263 Freightliner only
5.0 11.0 5.0 127 279 127 1.3 18 1 M110849
ISM 370 to 450 4.0 8.5 4.0 102 216 102 1.5 21 1 M085171
4.0 9.0 5.0 102 229 127 2.2 29 1 M090781
5.0 9.0 5.0 127 229 127 1.8 25 1 M090074
5.0 9.0 5.0 127 229 127 1.0 13 1 M090535 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 1.0 13 1 M100463 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 1.9 26 1 M100465 Best value, most popular
5.0 10.0 5.0 127 254 127 2.1 28 1 M100580 OE replacement
5.0 10.0 5.0 127 254 127 2.2 30 1 M100807 60” (1524mm) Long Body
5.0 10.0 5.0 127 254 127 1.6 22 1 M100944 OE replacement for higher HP
5.0 10.0 5.0 127 254 127 2.0 27 1 M101158 Silent Partner Stainless
5.0 10.0 5.0 127 254 127 2.0 27 1 M101181 Silent Partner Aluminized
5.0 10.0 5.0 127 254 127 2.1 28 1 M101263 Freightliner only
5.0 11.0 5.0 127 279 127 1.6 22 1 M110849
ISM 500 4.0 8.5 4.0 102 216 102 1.7 24 1 M085171
4.0 9.0 5.0 102 229 127 2.5 34 1 M090781
5.0 9.0 5.0 127 229 127 2.1 29 1 M090074
5.0 9.0 5.0 127 229 127 1.1 15 1 M090535 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 1.1 15 1 M100463 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 2.2 30 1 M100465 Best value, most popular
5.0 10.0 5.0 127 254 127 2.4 32 1 M100580 OE replacement
5.0 10.0 5.0 127 254 127 2.5 35 1 M100807 60” (1524mm) Long Body
5.0 10.0 5.0 127 254 127 1.9 26 1 M100944 OE replacement for higher HP
5.0 10.0 5.0 127 254 127 2.3 31 1 M101158 Silent Partner Stainless
5.0 10.0 5.0 127 254 127 2.3 31 1 M101181 Silent Partner Aluminized
5.0 10.0 5.0 127 254 127 2.4 32 1 M101263 Freightliner only
5.0 11.0 5.0 127 279 127 1.9 25 1 M110849
ISX 400 5.0 9.0 5.0 127 229 127 2.0 27 1 M090074
5.0 9.0 5.0 127 229 127 1.1 15 1 M090535 Low backpressure, off-hwy
4.0 9.0 5.0 102 229 127 2.4 32 1 M090781
5.0 10.0 5.0 127 254 127 1.1 15 1 M100463 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 2.1 29 1 M100465 Best value, most popular
5.0 10.0 5.0 127 254 127 2.3 31 1 M100580 OE replacement
5.0 10.0 5.0 127 254 127 2.4 33 1 M100807 60” (1524mm) Long Body
