Page 1408 - National Electrical Price Guide

National Electrical Price Guide

Assemblies
Branch EMT & Wire D/C Comp Coup, Strap & Power Shot 1/2" EMT 5#14
Qty Description Labor Cost Retail
10 1/2" EMT .20 3.85 6.49
58 #14 THHN Solid Copper .17 3.46 11.03
1 Red .25 Caliber Load .02 .11 .31
1 1/2" EMT Cast Comprsn Coupling .05 .36 1.85
1 1/2" EMT 1 Hole Steel Strap .03 .06 .30
.47 $7.85 $19.98
Branch EMT & Wire D/C Comp Coup, Strap & Power Shot 1/2" EMT 6#10
Qty Description Labor Cost Retail
10 1/2" EMT .20 3.85 6.49
69 #10 THHN Solid Copper .35 9.89 30.50
1 Red .25 Caliber Load .02 .11 .31
1 1/2" EMT Cast Comprsn Coupling .05 .36 1.85
1 1/2" EMT 1 Hole Steel Strap .03 .06 .30
.65 $14.27 $39.44
Branch EMT & Wire D/C Comp Coup, Strap & Power Shot 1/2" EMT 6#14
Qty Description Labor Cost Retail
10 1/2" EMT .20 3.85 6.49
69 #14 THHN Solid Copper .21 4.12 13.12
1 Red .25 Caliber Load .02 .11 .31
1 1/2" EMT Cast Comprsn Coupling .05 .36 1.85
1 1/2" EMT 1 Hole Steel Strap .03 .06 .30
.51 $8.50 $22.07
Branch EMT & Wire D/C Comp Coup, Strap & Power Shot 1/2" EMT w/Pull Wire
Qty Description Labor Cost Retail
10 1/2" EMT .20 3.85 6.49
12 Solid Pull Wire .04 .61 2.00
1 Red .25 Caliber Load .02 .11 .31
1 1/2" EMT Cast Comprsn Coupling .05 .36 1.85
1 1/2" EMT 1 Hole Steel Strap .03 .06 .30
.34 $4.99 $10.94
Branch EMT & Wire D/C Comp Coup, Strap & Power Shot 3/4" EMT 2#10
Qty Description Labor Cost Retail
10 3/4" EMT .30 6.82 12.35
23 #10 THHN Solid Copper .12 3.30 10.17
1 Red .25 Caliber Load .02 .11 .31
1 3/4" EMT Cast Comprsn Coupling .05 .59 2.35
1 3/4" EMT 1 Hole Steel Strap .03 .08 .50
.52 $10.89 $25.68
Branch EMT & Wire D/C Comp Coup, Strap & Power Shot 3/4" EMT 2#12
Qty Description Labor Cost Retail
10 3/4" EMT .30 6.82 12.35
23 #12 THHN Solid Copper .09 2.11 6.51
1 Red .25 Caliber Load .02 .11 .31
1 3/4" EMT Cast Comprsn Coupling .05 .59 2.35
1 3/4" EMT 1 Hole Steel Strap .03 .08 .50
.49 $9.70 $22.02
Branch EMT & Wire D/C Comp Coup, Strap & Power Shot 3/4" EMT 2#8, 1#10
Qty Description Labor Cost Retail
10 3/4" EMT .30 6.82 12.35
12 #10 THHN Solid Copper .06 1.72 5.30
23 #8 THHN Stranded Copper .14 5.53 17.74
1 Red .25 Caliber Load .02 .11 .31
1 3/4" EMT Cast Comprsn Coupling .05 .59 2.35
1 3/4" EMT 1 Hole Steel Strap .03 .08 .50
.60 $14.85 $38.56

ASSEMBLIES CONTAINING CONDUIT ARE BASED ON 10' LENGTHS
COST COLUMN IS A NATIONAL AVERAGE AND SHOULD BE VERIFIED FOR YOUR AREA
COPYRIGHT @ 1996-2019 by ELECTRICAL RESOURCES, INC.
