National Electrical Price Guide

Assemblies
Feeder EMT & Wire D/C Set Screw Coup & Beam Clamp 3-1/2" EMT 3#400
Qty Description Labor Cost Retail
1 3-1/2" Parallel Conduit Clamp .10 10.18 24.30
10 3-1/2" EMT 1.20 69.19 136.75
35 #400 THHN Stranded Copper 1.26 169.34 579.21
1 3-1/2" EMT Cast Set Screw Coupling .18 4.90 18.80
2.74 $253.61 $759.06
Feeder EMT & Wire D/C Set Screw Coup & Beam Clamp 3-1/2" EMT 3#400, 1#1/0
Qty Description Labor Cost Retail
1 3-1/2" Parallel Conduit Clamp .10 10.18 24.30
10 3-1/2" EMT 1.20 69.19 136.75
12 #1/0 THHN Stranded Copper .16 16.16 53.24
35 #400 THHN Stranded Copper 1.26 169.34 579.21
1 3-1/2" EMT Cast Set Screw Coupling .18 4.90 18.80
2.90 $269.78 $812.30
Feeder EMT & Wire D/C Set Screw Coup & Beam Clamp 3-1/2" EMT 3#500
Qty Description Labor Cost Retail
1 3-1/2" Parallel Conduit Clamp .10 10.18 24.30
10 3-1/2" EMT 1.20 69.19 136.75
35 #500 THHN Stranded Copper 1.47 213.98 721.21
1 3-1/2" EMT Cast Set Screw Coupling .18 4.90 18.80
2.95 $298.25 $901.06
Feeder EMT & Wire D/C Set Screw Coup & Beam Clamp 3-1/2" EMT 3#500, 1#1/0
Qty Description Labor Cost Retail
1 3-1/2" Parallel Conduit Clamp .10 10.18 24.30
10 3-1/2" EMT 1.20 69.19 136.75
35 #500 THHN Stranded Copper 1.47 213.98 721.21
12 #1/0 THHN Stranded Copper .16 16.16 53.24
1 3-1/2" EMT Cast Set Screw Coupling .18 4.90 18.80
3.11 $314.41 $954.30
Feeder EMT & Wire D/C Set Screw Coup & Beam Clamp 3-1/2" EMT 4#400
Qty Description Labor Cost Retail
1 3-1/2" Parallel Conduit Clamp .10 10.18 24.30
10 3-1/2" EMT 1.20 69.19 136.75
46 #400 THHN Stranded Copper 1.66 222.56 761.24
1 3-1/2" EMT Cast Set Screw Coupling .18 4.90 18.80
3.14 $306.84 $941.09
Feeder EMT & Wire D/C Set Screw Coup & Beam Clamp 3-1/2" EMT 4#400, 1#1/0
Qty Description Labor Cost Retail
1 3-1/2" Parallel Conduit Clamp .10 10.18 24.30
10 3-1/2" EMT 1.20 69.19 136.75
12 #1/0 THHN Stranded Copper .16 16.16 53.24
46 #400 THHN Stranded Copper 1.66 222.56 761.24
1 3-1/2" EMT Cast Set Screw Coupling .18 4.90 18.80
3.29 $323.00 $994.34
Feeder EMT & Wire D/C Set Screw Coup & Beam Clamp 3-1/2" EMT 4#500
Qty Description Labor Cost Retail
1 3-1/2" Parallel Conduit Clamp .10 10.18 24.30
10 3-1/2" EMT 1.20 69.19 136.75
46 #500 THHN Stranded Copper 1.93 281.23 947.87
1 3-1/2" EMT Cast Set Screw Coupling .18 4.90 18.80
3.41 $365.50 $1127.72

ASSEMBLIES CONTAINING CONDUIT ARE BASED ON 10' LENGTHS
COST COLUMN IS A NATIONAL AVERAGE AND SHOULD BE VERIFIED FOR YOUR AREA
