Measuring and pre-setting equipment
Tool pre-setting

Edge finder
with light display and spring feeler tang
Application: Execution: Advantage:
For precise alignment of workpiece reference sur- ƒ Functional components are hardened and polished ƒ 3-D model also suitable for moving the workpiece
faces or edges to determine the bore centre points ƒ Ident. No. 025: With acoustic signal in the Z direction (vertically)
centrally to the working spindle.
2

D Clamping Technology
L1 1
L
Ident. No. 020–025 Ident. No. 015 ① Spring ball Ø 10,000
② Tracer path approx. 3 mm

Sensor design 3-D 3-D 3-D audible
Probe head Ø (mm) 10 10 10
Clamping shank Ø D (mm) 16 20 20
Clamping length L1 (mm) 35 45 45
Length L (mm) 111 106 131
Reading Light indicator Light indicator Audible light indicator
Repeat accuracy (+/-) (mm) 0.01 0.01 0.01
020
025
015
Ident. No.
23923... Unit price, € O. R. O. R. O. R.
Prod. group 298
Zero adjustment device with dial gauge
Application: Execution:
The device is placed on the workpiece. Using the ƒ Height adjustment gauge to determine position
machine spindle, the cutting tool is moved up to the of workpiece surface in the Z direction on milling
probe until the indicator is at zero for the first time. machines and lathes, can also be used horizontally
Now the reference dimension for the distance from
the workpiece of 100 mm has been reached.
Scale value (mm) 0.01
Reference dimension (mm) 100
Repeat accuracy (+/-) (mm) 0.01
010
Ident. No.
23931... Unit price, € O. R.
Prod. group 227

Zero adjustment device, stainless steel version
With dial gauge

Application: ƒ Made of stainless steel, probe bolt with two feeler
For accurately determining the position of work- diameters to prevent any tilting of the contact
piece surfaces or workpiece lengths in the Z direc- surface, precision-ground, inclined contact
tion on lathes or milling machines. The device is surface for the dial gauge, enhanced repeatability.
placed on the workpiece. It is then moved carefully ƒ Zero point probe for improved guidance, for even
towards the device with the spindle stationary until more precise determination of the position of the
the dial gauge shows ‘0’. The reference dimension workpiece surface in the Z direction on milling
of 50 mm is now reached. Allowance has been made machines and lathes.
for a safety spring travel of approx. 0.5 mm for going ƒ Material: stainless steel
beyond the 50 mm.
scope of supply and services:
Execution: Zero adjustment device in a wooden case with serial 1 2
ƒ With dial gauge number and test certificate
Scale value (mm) 0.01
Reference dimension (mm) 50 49,5 50
Repeat accuracy (+/-) (mm) 0.005
010
Ident. No.
23934... Unit price, € O. R.
Prod. group 227 Ø 65
① = Gripping grooves
② = Spring-mounted button
