Lathe and cut-off tools accessories
Lathe chuck

Workpiece stop

Application: Execution: ƒ Stop is coloured blue
For clamping short parts on lathe chucks. ƒ Fastened with 3 magnets that are built into the ƒ Contact surfaces are polished
limit stop by simply placing on the lathe chuck ƒ Material: aluminium
body.

150
55
Clamping Technology
25
Ident. No. 015
1 = Workpiece stop Workpiece stop
2 = Workpiece
Workpiece stopper height 15 mm 20 mm 25 mm 30 mm 35 mm
Min. jaw width (mm) 25 25 25 25 25
Max. jaw width (mm) 55 55 55 55 55
For min./max. workpiece Ø 15-130 mm 15-130 mm 15-130 mm 15-130 mm 15-130 mm
015
Ident. No.
035
030
020
025
22474... Unit price, € O. R. O. R. O. R. O. R. O. R.
Prod. group 264
Workpiece stop set
Application: Execution: ƒ Contact surfaces are polished
For clamping short parts on lathe chucks. ƒ Fastened with 3 magnets that are built into the ƒ Material: aluminium
limit stop by simply placing on the lathe chuck
body. scope of supply and services:
ƒ Stop is coloured blue Complete set in wooden case

150
55
25

1 = Workpiece stop Workpiece stop
2 = Workpiece
Workpiece stopper height 15 mm | 20 mm | 25 mm | 30 mm | 35 mm
Min. jaw width (mm) 25
Max. jaw width (mm) 55
For min./max. workpiece Ø 15-130 mm
100
Ident. No.
22474... Set price, € O. R.
Prod. group 264
Pressure collets type 161 E and 173 E
Clamp bridge rising in 1 mm increments

Application: Notes:
Collets of type 161 E and 173 E with clamp bridge Collets for square and hexagonal workpieces on
rising in 1 mm increments for clamping cylindrical request.
workpieces.
Min. clamping range (mm) 3 3
Max. clamping range (mm) 26 42
Clamping range increasing by 0.5 mm 1 mm
Collet type 161E 173E
010
Ident. No.
020
22366... Unit price, € (O. R.) (O. R.)
Prod. group 250
