Positioning pieces
Parallel rests

Parallel rest sets

Application: ƒ Height tolerance within a 0.01 mm pair
For parallel support of workpieces in machine vices, ƒ Hardened and polished
on machine tools or on marking-off plates. ƒ In pairs, tolerance IT 5, nominal width to DIN ISO
Execution: 2768-1, tolerance class m
ƒ Made of steel scope of supply and services:
ƒ The different dimensions create a multitude of In wooden case with 14 pairs of packing pieces.
combination possibilities.
Parallel rest length (mm) 150 150
Parallel rest width (mm) 10 10
Parallel rest height 14 mm | 16 mm | 18 mm | 14 mm | 16 mm | 18 mm |
Clamping Technology
20 mm | 22 mm | 24 mm | 20 mm | 22 mm | 24 mm |
26 mm | 28 mm | 30 mm | 26 mm | 28 mm | 30 mm |
32 mm | 35 mm | 40 mm | 32 mm | 35 mm | 40 mm |
45 mm | 50 mm 45 mm | 50 mm
Nominal tolerance, height 14-30 mm - +/- 0.020 mm
Pair tolerance 0.01 mm 0.01 mm
010
020
Ident. No.
26256... Set price, € O. R. O. R.
Prod. group 264
Parallel rest sets

Application: Execution:
For parallel support of workpieces in machine vices, ƒ In pairs, tolerance IT 5, nominal width to DIN ISO
on machine tools or on marking-off plates. 2768-1, tolerance class m

Composition of set Width x height: 8 x 11 Width x height: 8 x 11
8 x 16 8 x 21 8 x 26 8 x 16 8 x 21 8 x 26
Width x height: 2 x 5 8 x 31 8 x 36 10 x 13 8 x 31 8 x 36 10 x 13
2 x 10 2 x 15 2 x 20 10 x 18 10 x 23 10 x 10 x 18 10 x 23 10 x
3 x 6 3 x 11 3 x 16 3 28 10 x 33 10 x 38 28 10 x 33 10 x 38
x 21 4 x 7 4 x 12 4 x 12 x 15 12 x 20 12 12 x 15 12 x 20 12
17 4 x 22,5 x 8 5 x23 x 25 12 x 30 12 x 35 x 25 12 x 30 12 x 35
6 x 9 6 x 14,6 x 19 12 x 40 14 x 17 14 x 12 x 40 14 x 17 14 x
6 x 24 22 14 x 27 14 x 32 22 14 x 27 14 x 32
14 x 27 14 x 32 14 x 14 x 27 14 x 32 14 x
37 14 x 42 37 14 x 42
Min. set height (mm) 2 8 8
Max. set height (mm) 24 42 42
Parallel rest length (mm) 100 125 150
Pair tolerance IT 5 IT 5 IT 5
010
020
030
Ident. No.
26254... Set price, € O. R. O. R. O. R.
Prod. group 264
Angle plates
made from grey cast iron
Application: ƒ Squareness tolerance 0.04/100 mm
For attaching a workpiece perpendicular to the base ƒ With machined clamping surfaces and reinforce-
on which the angle plate is standing. ment ribs
Execution: Notes:
ƒ Made from grey cast iron Other sizes on request. Delivered ex-works, post-
ƒ Lightweight and sturdy design age and packaging excluded.
H
Length L (mm) 150 200 275 400
Width B (mm) 75 100 150 225
Height H (mm) 100 150 200 300
Weight (kg) - - 15 45
Ident. No.
030
010
040
26260... Unit price, € O. R. 020 O. R. O. R. +
O. R.
Prod. group 264
L B
