Hand-held devices
Micrometers

Electronic micrometer DIN 863

Application: ƒ ON/OFF
For measuring e. g. shaft diameters, external dimen- ƒ Zero setting at any position
sions on workpieces etc. ƒ mm/inch switch-over
Execution: scope of supply and services:
ƒ Carbide measuring faces In a case, with battery (1 x type SR 44, 1.55 V) and
ƒ Advanced friction coupling for consistent, repeat- setting gauges
able measuring force
Min./max. length measuring range Digit increment (mm) Measuring surface Ø (mm) Measuring spindle increments (mm) 31406...
ID no.
0-25 mm 0.001 6.5 0.5 005 O. R.
25-50 mm 0.001 6.5 0.5 025 O. R.
50-75 mm 0.001 6.5 0.5 050 O. R.
75-100 mm 0.001 6.5 0.5 075 O. R.
Unit price, € Measuring equipment
Prod. group 3BJ

Electronic micrometer set
0-100 mm DIN 863

Application: ƒ Zero setting at any position
For measuring e. g. shaft diameters, external dimen- ƒ mm/inch switch-over
sions on workpieces etc. ƒ Including setting gauges
Execution: ƒ Including setting gauges
ƒ Carbide measuring faces scope of supply and services:
ƒ Advanced friction coupling for consistent, repeat- In a case, with battery (1 x type SR 44, 1.55 V) and
able measuring force setting gauges
ƒ ON/OFF
Min./max. length measuring range Digit increment (mm) Measuring surface Ø (mm) Measuring spindle increments (mm) 31406...
ID no.
0-100 mm 0.001 6.5 0.5 400 O. R.
Set price, €
Prod. group 3BJ

Measuring instrument holder

Application: ƒ For micrometers with measuring ranges up to
For mounting measuring instruments, e.g. microm- 300 mm
eters, to keep both hands free while measuring.
Technical Data:
Execution: ƒ Max. clamping width: 16 mm
ƒ Clamping element with adjustable angle
020
Ident. No.
31416... Unit price, € O. R.
Prod. group 3BC
Measuring force testing system for external micrometers

Application: ƒ 3 screw-on extensions for micrometers up to
For testing the measuring force between microm- measuring range 100 mm
eter measuring faces (up to Ø 8 mm).
scope of supply and services:
Execution: In a case
ƒ Force measuring cell for micrometers
ƒ Extensions for micrometers up to 100 mm Technical Data:
ƒ Min./max. force of measuring range: 5-10 N
Ident. No.
100
31417... Measuring force test system Set price, € O. R.
Prod. group 3BC
