Hand-held devices
Micrometers

Plane-parallel test glasses sets
For measuring range 0–25 mm

Application: scope of supply and services:
For testing the flatness and parallelism of 0–25 mm In a case
micrometer measuring faces.
Ident. No.
100
31419... Plane-parallel test glasses Set price, € O. R.
Prod. group 3BC
Electronic micrometer
Disc-shaped measuring faces DIN 863

? Measuring equipment

Application: ƒ ON/OFF
For measuring tooth span (Wk) on cogs as of module ƒ Zero setting at any position
0.5, for recesses, groove distances etc. ƒ mm/inch switch-over
Execution: ƒ ABS function
ƒ Measuring faces made of hardened steel scope of supply and services:
ƒ Advanced friction coupling for consistent, repeat- In a case, with battery (1 x 1.5 V type SR44)
able measuring force
Min./max. length measuring
range 0-25 mm 25-50 mm 50-75 mm 75-100 mm
Digit increment (mm) 0.001 0.001 0.001 0.001
Measuring surface Ø (mm) 20 20 20 20
Measuring spindle increments 0.5 0.5 0.5 0.5
(mm)
075
050
Ident. No.
025
005
31610... Unit price, € O. R. O. R. O. R. O. R.
Prod. group 3BJ
Electronic universal micrometer DIN 863
7 interchangeable gauge slide pairs
?

Application: ƒ Zero setting at any position
For measuring various external dimensions. ƒ mm/inch switch-over
ƒ ABS function
Execution:
ƒ Measuring faces made of hardened steel scope of supply and services:
ƒ Advanced friction coupling for consistent, repeat- In a case, with battery (1 x 1.5 V type SR44)
able measuring force
ƒ ON/OFF
Min./max. length measuring
range 0-25 mm 25-50 mm 50-75 mm 75-100 mm
Digit increment (mm) 0.001 0.001 0.001 0.001
Measuring surface Ø (mm) 8 8 8 8
Measuring spindle increments 0.5 0.5 0.5 0.5
(mm)
050
075
005
025
Ident. No.
31620... Unit price, € O. R. O. R. O. R. O. R.
Prod. group 3BC
