P. 125
Reaming tools
Carbide/solid carbide machine reamers
f steel 11726... f steel 11726... Metal cutting tools
h6 1300 ID no. h6 1300 ID no.
(mm/U) (mm/U)
mm mm mm mm mm mm mm mm
7.4 H7 109 31 8 6 0.12 074 O. R. 9.2 H7 125 36 10 6 0.15 092 O. R.
7.5 H7 109 31 8 6 0.12 075 O. R. 9.3 H7 125 36 10 6 0.15 093 O. R.
7.6 H7 117 33 8 6 0.12 076 O. R. 9.4 H7 125 36 10 6 0.15 094 O. R.
7.7 H7 117 33 8 6 0.12 077 O. R. 9.5 H7 125 36 10 6 0.15 095 (O. R.)
7.8 H7 117 33 8 6 0.12 078 O. R. 9.6 H7 133 38 10 6 0.15 096 O. R.
7.9 H7 117 33 8 6 0.12 079 O. R. 9.7 H7 133 38 10 6 0.15 097 O. R.
8 H7 117 33 8 6 0.15 080 O. R. 9.8 H7 133 38 10 6 0.15 098 O. R.
8.1 H7 117 33 8 6 0.15 081 O. R. 9.9 H7 133 38 10 6 0.15 099 O. R.
8.2 H7 117 33 8 6 0.15 082 O. R. 10 H7 133 38 10 6 0.15 100 O. R.
8.3 H7 117 33 8 6 0.15 083 O. R. 11 H7 142 41 10 6 0.15 110 O. R.
8.4 H7 117 33 8 6 0.15 084 O. R. 12 H7 151 44 10 6 0.15 120 O. R.
8.5 H7 117 33 8 6 0.15 085 O. R. 13 H7 151 44 10 8 0.15 130 O. R.
8.6 H7 125 36 10 6 0.15 086 O. R. 14 H7 160 47 12.5 8 0.18 140 O. R.
8.7 H7 125 36 10 6 0.15 087 O. R. 15 H7 162 50 12.5 8 0.18 150 O. R.
8.8 H7 125 36 10 6 0.15 088 O. R. 16 H7 170 52 12.5 8 0.18 160 O. R.
8.9 H7 125 36 10 6 0.15 089 O. R. 18 H7 182 56 14 8 0.18 180 O. R.
9 H7 125 36 10 6 0.15 090 O. R. 20 H7 195 60 16 8 0.2 200 O. R.
9.1 H7 125 36 10 6 0.15 091 O. R. Unit price, €
Prod. group 117
NC machine reamer, solid carbide, with uniform shank DIN Similar to 8093
for universal use up to 1300 N/mm2
HA
VHM 0,001
7–8°
Application: carbide, from dia. of 12.21 mm up, solid carbide
For creating fit tolerances (nominal size=0/+0.003 head)
mm) in through holes and blind holes on NC ma-
chines for the material groups of steel, (stainless Advantage:
steel), non-ferrous metals, cast iron and special innovative cutting geometry ensures extremely
alloys up to a strength of 1300 N/mm . 2 good dimensional accuracy and process reliability
top-quality solid carbide cutting material ensures
Execution: extremely long service life
precision-ground design with 7-8° left-hand spiral, high-quality boring (roundness, finish quality)
type B, (up to dia. of 12.20 mm made from solid
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11730 18 15 12 10 8 20 20 20 20 18 16 18 12 8 8 6
f steel 11730... f steel 11730...
h6 1300 ID no. h6 1300 ID no.
(mm/U) (mm/U)
mm mm mm mm mm mm mm mm
0.90 0-0.003 mm 34 6 1 3 0.12 090 O. R. 1.03 0-0.003 mm 34 6 1 3 0.12 103 O. R.
1 0-0.003 mm 34 6 1 3 0.12 100 O. R. 1.48 0-0.003 mm 40 8 2 3 0.12 148 O. R.
1.01 0-0.003 mm 34 6 1 3 0.12 101 (O. R.) 1.49 0-0.003 mm 40 8 2 3 0.12 149 O. R.
1.02 0-0.003 mm 34 6 1 3 0.12 102 O. R. 1.50 0-0.003 mm 40 8 2 2 0.12 150 (O. R.)
www.buypremiumtools.com 125
