Drilling tools
Conical countersinks and deburrers

Conical countersink set 60° HSS three-way cutter DIN 334 C Metal cutting tools
for universal use up to 1000 N/mm 2

Z HA
HSS TiN
3
Application: ƒ Ident. No. 905, 915, 925, 935: profile-ground
For 60° counterboring for the material groups of triple-edge countersink with standard relief
steel, (stainless steel), non-ferrous metals, and (cast
iron) up to a strength of 1000 N/mm . 2 Advantage:
ƒ radial relief ensures optimum chip breaking
Execution:
ƒ Ident. No. 900, 910, 920, 930: profile-ground
triple-edge countersink with radial relief

Ident. No. 900–905, 920–925 Ident. No. 910–915, 935

Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11498900 30 20 10 8 40 70 60 50 40 30 30 15
11498905 30 20 10 8 40 70 60 50 40 30 30 15
11498910 30 20 10 8 40 70 60 50 40 30 30 15
11498915 30 20 10 8 40 70 60 50 40 30 30 15
11498920 30 20 10 8 40 70 60 50 40 30 30 15
11498925 30 20 10 8 40 70 60 50 40 30 30 15
11498930 30 20 10 8 40 70 60 50 40 30 30 15
11498935 30 20 10 8 40 70 60 50 40 30 30 15

Cutting material HSS HSS HSS HSS
Surface Uncoated Uncoated TiN TiN
Composition of set Number of pieces in assortment/set (PCS) 11498... 11498... 11498... 11498...
ID no. ID no. ID no. ID no.
8.0/10.0/12.5/16.0/20.0 5 900 O. R. 905 O. R. 910 O. R. 915 O. R.
6.3/8.0/10.0/12.5/16.0/20.0/25.0 7 920 O. R. 925 O. R. 930 O. R. 935 O. R.
Set price, €
ORION = Prod. group 103
a = Prod. group 114
Conical countersink 60° solid carbide, three-edge
For universal use up to 1300 N/mm 2 DIN 334 C

Z HA
HM
3
Application: Advantage:
For producing countersinks 60° in steel stainless ƒ Radial grinding relief to ensure optimum chip
steel, non-ferrous metals, cast iron and special breaking
alloys material groups up to a strength of 1300 N/ ƒ Innovative cutting geometry ensures good cutting
mm . 2 performance and good surface qualities
Execution:
ƒ Profile-ground three-edge countersink with radial
grinding relief
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11498308-325 60 45 20 20 15 80 150 120 100 80 60 60 40 20 20 20
Surface Uncoated
f steel 1300 ˜ (mm/U) 11498...
ID no.
mm mm mm mm
8 2 6 50 0.08 308 O. R.
10 2.5 8 50 0.09 310 O. R.
12.5 3.2 8 56 0.1 312 O. R.
16 4 10 63 0.12 316 O. R.
20 5 10 67 0.13 320 O. R.
25 6.3 10 71 0.14 325 O. R.
Unit price, €
Prod. group 114
