P. 95
Drilling tools
Conical countersinks and deburrers
Conical countersink, 60°, HSS, multi-flute cutter
For universal use up to 1000 N/mm 2
Metal cutting tools
Metal cutting tools
Z HA
HSS
5
Application: Advantage:
For countersinking 60° in the material groups High number of flutes for quiet cutting
steel, non-ferrous metals and cast materials up to a performance
strength of 1000 N/mm . 2 Innovative cutting geometry provides for optimal
Execution: chip breaking
Profile-ground multi-flute countersink with straight Very good cutting performance and surface quality
(chatter-free)
cutter
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11495308-320 30 20 10 10 40 70 40 40 60 60 30 20
Number of cutting f steel 700 (mm/U) 11495...
edges (PCS) ID no.
mm mm mm mm
8 1.5 50 8 5 0.1 308 O. R.
12.5 2 50 8 5 0.13 312 O. R.
16 3.2 60 10 7 0.14 316 O. R.
20 5 63 10 7 0.16 320 O. R.
Unit price, €
Prod. group 114
60° conical countersink, HSS, triple cutter
for universal use up to 1000 N/mm 2 DIN 334 D
Z MK
HSS
3
Application: Advantage:
For 60° counterboring for the material groups of radial relief ensures optimum chip breaking
steel, (stainless steel), non-ferrous metals, and (cast innovative cutting geometry provides excellent
iron) up to a strength of 1000 N/mm . 2 cutting performance and good finish quality
Execution:
profile-ground triple-edge countersink with radial
relief
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11498226-263 30 20 10 10 40 70 60 50 40 30 30 15
Cutting material HSS
f steel 700 (mm/U) 11498...
ID no.
mm mm mm
25 6.3 112 MK 2 0.18 226 O. R.
31.5 10 118 MK 2 0.21 231 O. R.
40 12.5 150 MK 3 0.25 240 O. R.
50 16 160 MK 3 0.28 250 O. R.
63 20 190 MK 4 0.33 263 O. R.
Unit price, €
Prod. group 114
Conical countersink, 60°, HSS, multi-flute cutter
For universal use up to 1000 N/mm 2
MK
HSS
Application: Advantage:
For countersinking 60° in the material groups High number of flutes for quiet cutting
steel, non-ferrous metals and cast materials up to a performance
strength of 1000 N/mm . 2 Innovative cutting geometry provides for optimal
Execution: chip breaking
Profile-ground multi-flute countersink with straight Very good cutting performance and surface quality
(chatter-free)
cutter
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11495330-360 30 20 10 10 40 70 60 50 40 30 30 15
Number of cutting f steel 700 (mm/U) 11495...
edges (PCS) ID no.
mm mm mm
25 7 125 MK 2 9 0.18 330 O. R.
