From a fixed ac voltage, a variable ac output voltage can be made available
               using SCR–diode combinations as shown in Fig. 14.42.
                  In the positive half cycle of the input voltage when terminal A is positive,

               SCR T  and diode D  will conduct. The conduction angle is decided by the
                        1
                                        2
               time at which the SCR, T  will be triggered. In the negative half cycle,
                                              1
               terminal B is positive, and hence SCR T  and diode D  will conduct. The
                                                                2
                                                                                1
               time of triggering of the gate of SCR, T  will decide the conduction angle in
                                                               2
               the negative half cycle. By changing the firing angle of the SCRs, a variable
               ac voltage will be available across the load, and hence load current will

               change.



                                                         14.11 DIAC
               Like an SCR, DIAC is also a member of the thyristor family. A DIAC is a

               bidirectional diode which conducts in both directions whereas a diode
               conducts in one direction. Unlike an ordinary diode, a DIAC conducts only

               when the applied voltage reaches the breakover voltage. DIAC is a two-
               terminal device without a gate terminal. When the applied voltage between its

               two terminals, which are termed A  and A , is raised to the breakover
                                                                  2
                                                         1
               voltage, the DIAC starts conducting. The symbolic representation and V–I
               characteristics of a DIAC have been shown in Fig. 14.43. Terminal A  is
                                                                                                   1
               called anode 1 and terminal A  is called anode 2.
                                                   2



                                                        14.12 TRIAC
               A TRIAC combines in itself two SCRs connected in anti-parallel or inverse-

               parallel with one gate terminal as has been shown in Fig.14.44 (a). The four
               layers n  p  n  p  form one SCR and the other four layers p  n  p  n  form the
                                                                                                 4
                                                                                          2
                                                                                      1
                         1
                                   3
                                                                                             2
                            2
                                3
               other SCR. Layer p  is common to both SCRs and is used as the gate as
                                       2
               shown.
