DYNAMIC TRIM CONTROL SYSTEMS
                                                                            OceanLink® Series
      MARINE INSTRUMENTS



              52mm Gauges for sports boats


              OceanLink 52 mm Gauges are connected directly to any OceanLink Master unit using the patented
              EasyLink serial bus connection. Up to 16 EasyLink gauges for each Tachometer can be
              daisy-chained together. OceanLink Gauges have white and black dial version, which is always
              completed with bezel in identical color. Optional Chrome Bezel is available as decorative accessory.



               ENGINE LOAD
               AMI Code  Supplier Code  Description
               1610950  N02-226-210  OL Engine Load 0-100% Black



                                                                                    OceanLink® Engine
               PRESSURE                                                               Load Gauge

               AMI Code  Supplier Code  Description
               1610955  N02-140-508  OL Boost Pressure 3 bar Black EL
               1610960  N02-140-156  OL Engine Oil Pressure 0-10 bar Black EL
               1610961  N02-140-160  OL Engine Oil Pressure 0-10 bar / 145 psi White
               1610962  N02-140-512  OL Engine Oil Pressure 150 psi Black
               1610965  N02-140-154  OL Transmission Oil Pressure 0-25 bar Black EL
               1610966  N02-140-158  OL Transmission Oil Pressure 0-25 bar/360PSI White
               1610968  N02-140-516  OL Transmission Oil Pressure 0-300PSI Black  OceanLink® Transmission    OceanLink® Engine Oil
                                                                              oil pressure gauge  pressure Gauge
              • AMP Superseal Easylink
              • < 100 mA                                        Aftermarket package:
              • 270° pointer deflection angle                   Gauge, Bezel, Rubber Seal,
              • Reverse polarity protection                     Spinlock, Installation Instructions,
              • Anti-fog double layer plastic lens              Safety Instructions
              • Front & rear protection rating IPX5
              • Operating temperature range -20 °C / +70 °C


               BATTERY STATUS
               AMI Code  Supplier Code  Description
               1610980  N02-413-066  OL Voltmeter 8-16V Black
               1610981  N02-413-074  OL Voltmeter 8-16V White/Chrome
               1610984  N02-413-058  OL Voltmeter 18-32V Black
               1610985  N02-413-060  OL Voltmeter 18-32V White/Chrome           OceanLink® Voltmeter


              • AMP Superseal Easylink                          Aftermarket package:
              • < 100 mA                                        Gauge, Bezel, Rubber Seal, Spinlock, Installation
              • 270° pointer deflection angle                   Instructions,
              • Reverse polarity protection                     Safety Instructions
              • Anti-fog double layer plastic lens
              • Front & rear protection rating IPX5
              • Operating temperature range -20 °C / +70 °C



        Marine Instruments | AMI Marine Catalogue                                                          12
