DYNAMIC TRIM CONTROL SYSTEMS
MARINE ANTENNAS AM/FM Radio receiving fiberglass whip

Description
AMI Code
Supplier Code
FM/DB/12 AM/FM 2.40m
1280452
0118-2
Fastfit AM-FM 1.5m 3 DB NYL
1280458
9032
9076
1280459
Fastfit FM 2.45M 6DB Nylon Ferrule
FM/DB/12 AM/FM 2.40m
Features:
Features:
• Fiberglass Whip Length: 2,4mt (8ft).
• Fiberglass Whip Length: 1,5mt (5ft).
• Weight: 400gr/ (14 oz). Fastfit AM-FM 1.5m 3 DB NYL
• Frequency: 0,5-1,6/88-108.
• Fixage: 4 way nylon base (included). • DC Closed: No.
• Termination: 5,0 mt(15ft) RG-58. • Weight: 300gr (36 oz).

0118-2 09032

TV Antennas & optional brackets

AMI Code Supplier Description
Code
1285036 331-7 Sail Bracket with 15mtr cable

1285037 331-8 Snap on Bracket with 5 mtr cablet
1285038 331-9 Mirror Bracket with 5 mtr cable
1282204 00198 Nylon Fixed GPS deck mount 1”`14 threads
1282090 00331 Whip Style TV DVB-T TNT 25cm with adaptor
base, power supply kit and 5 mt.cable
1282091 00331-2 Whip Style TV DVB-T TNT 25cm with snapon
base, power supply kit and 5 mt.cable

331-9

Features:
• Frequency: 175-240/470-8 60 MHz.

• Gain: 24 db.
• Impedance: 70 Ohm.
• Output Voltage: +26 dbm.
• Noise Figure: 1,9 db.
• Power: 12VDC-50 Ma.
• Connection: Female.
• Fitting: Hole dia 12mm or adapter included 00198
for 1”-14 thread female.

Audio Visual Communication | AMI Marine Catalogue 4
