HRL-2070U/G Remote Controlled AMI Code Supplier Code Voltage

LED Searchlight 1440060 HRL-2070U/G 12V
24V
HRL-2070U/G
1440061
Unit to the same specification as the
conventional searchlight HR-1012 model
below - with new LED lamp SANSHIN SEARCHLIGHTS

HR-1012 Compact Searchlight AMI Code Supplier Code Voltage

1440060 1440060 12V
Features: 1440061 1440061 24V
• Reflector dia: 1060;100-70cut(mm). • Rated Current: 10A/5A.
• Lamps: Halogen lamp x2. • JCD12V-55WDX/ JCD24V-55WDX.
• Beam Spread: Horizontal • Focus Adjustment: Fixed.
Approx. 7 Deg, Vertical Approx. 5 Deg. • Elevation & Turning: Remote Control.
• Elevation angle: Up 9 Deg, Down 17 Deg. • Turning angle: 360 Deg (endless).
• Elevation Speed: 2.8 Deg/mm. • Material: Aluminium
• Turning Speed: High 31 Deg/mm, alloy die casting.
Low 20 Deg/mm.
• Colour (Standard): MunsellN-9.5 (White).
• Control Panel: CPF53 (Main) CPF54 (Sub)

NEW LED Upgrade for HR-1012

Upgrading to LED means no more bulb replacements. The Sanshin LED
Upgrade for the Sanshin HR-1012 searchlight is as simple as removing the conventional
halogen unit and replacing with the LED module of the same size and template. Purchase the LED
unit only to upgrade, no additional fittings required. Suited to DC12V/DC24V. LED Module offers
40,000h of use.

Control options AMI Code Supplier Code Description
Choose from electric remote control (CPF53), or 1441001 BC6800197 LED Upgrade Module
wireless control (Available as 2-station control via sub
remote control panel)

Very simple to install, the LED module is the
same footprint as the existing halogen unit.
Installation is as simple as removing
faceplates and fasteners, connecting the new
unit and then tightening the casing back up.

Old halogen style assembly New LED assembly installed
