SEARCHLIGHGTS Sanshin Searchlights AMI Code Supplier Code
DYNAMIC TRIM CONTROL SYSTEMS
Sanshin searchlights are compact, suitable to both leisure and commercial

vessels and feature hard wearing ruggedised casings, simple installation,
and new LED upgrades on some models.

Searchlight HR1170U12
1440065
HR-1170U12
Features:
• Lamp Housing Materials: Aluminium alloy • Elevation Speed: Up about 7deg./sec. Down
die casting. about 6 deg./sec.
• Base Materials: Aluminium alloy die casting. • Turning Speed: High about 30deg./sec.Low
• Reflector: High quality parabolic glass. about 11 deg/sec.

• Applicable Lamps: SCB-0155. • Degree of Protection: IP56.
• Built in Ballast: 24V-BH. • Weight: 13.5kg.
• Input Voltage: DC12V/DC24V
• Input Current: About 8 A(12V)/4A(24V).
• Peak Beam Candle Power: 6000,000cd.
• Beam Spread: About 7”.
• Operation Method: Electric remote control.
• Elevation Angle: 360deg (Endless).

Searchlight HRX-150

Features:
• Reflector Dia: 1060; 218-150cut(mm). • Turning Angle: 360 Deg (Endless).
• Rated Current: 17A/8.5A. • Elevation Speed: 7.5 deg/mm.

• Lamps: Xenon Lamp. • Turning Speed: High approx. 27 Deg/mm,
• Beam Spread: Approx. 1 Deg. Low approx. 11 Deg/mm.
• Focus Adjustment: Electric • Material: Aluminium alloy
remote control. die casting.
• Elevation & Turning: Electric remote control. • Colour (Standard):
• Elevation Angle: Up 18 Deg, Down 30 Deg. MunsellN-95.

AMI Code Supplier Code
1440070 HRX-150

Require Spare Parts?

AMI stock a wide selection of spare parts,
globes, components and accessories for
searchlights.
