Page 190 - BA2 Integrated Workbook - Student 2017

Chapter 12

4.1 Characteristics of the normal distribution

In this case the data is symmetrical and peaks in the centre. This is called a
normal distribution. We can draw a line around this distribution to show the shape
more clearly. This is called a bell curve.
Mean

Frequency

distribution

Standard deviation

 The mean is shown in the centre of the diagram.

 The curve is symmetrical about the mean. This means that 50% of the values
will be below the mean and 50% of the values will be above the mean.

 The mean, median and mode will all be the same for a normal distribution.

 The total area under the curve equals 1.

 The standard deviation shows how far the values spread out from the mean

182
