LIGHTING



           Step Lights

                                                                                                                     ELECTRICAL

           LED Step Lights                                      Compact Low Profile Step Lights

           „  Dual voltage 12/24V surface fit 3 LED light with base gasket,   „  Slim modern design, suitable for many applications such
             clear lens and coloured LED’s.                      as :- step illumination, cabinet lighting, under seat lighting,
           „  Lux reading @ 1 metre – White LED’s - 3 lux (579-1)  ambient lighting.
                                                                „  Surface Mount. Supplied with Grey and White Endcaps.
                                                                „  Supplied with Gasket. IP67.                       EMERGENCY
                                                                „  Capable of continuous operation at 32 volts.
                                                                „  549-1 Lux reading @ 1Mtr 36. Ra 84 Approx

                                                                                                                     GENERAL







           Part No.  A  B  C        LED/Colour      Kg  Voltage
           579-1   83  30  8         3/White        0.02 12/24v
           579-2   83  30  8          3/Red         0.02 12/24v  Part No.  A  B  C  D      LED/Colour    Kg  Voltage  HANDLES
           579-3   83  30  8          3/Blue        0.02 12/24v  549-1  105  18  9  90      6/White     0.015 12/24v
           579-4   83  30  8         3/Amber        0.02 12-24v  549-2  105  18  9  90      6/Blue      0.015 12/24v
           579-5   83  30  8         3/Green        0.02 12-24v  549-3  105  18  9  90      6/Red       0.015 12/24v
                                                                                                                     HINGES

           Strip Lights



           LED Linear Strip Lights                               PRODUCT FOCUS


           „  High quality die cast aluminium housing in powder coated                                               IRONWORK
             white.
           „  Available in 2 lengths - 156mm & 207mm.
           „  Available in 3 switching options – Non-switched, touch switch
             and PIR.
           „  10-30 Volts.
           „  IP67 Waterproof.                                                                                       LIGHTING
           „  Approval : CE R10 EMC UKCA.                                                      More info online
           „  156mm Lamp 306Lux @ 1 mtr 81.6Ra Colour Temp 5090.
           „  207mm Lamp 602Lux @ 1 mtr 81.6Ra Colour Temp 5090.

                              A
                                                                                                                     LOCKS

                 B

                              D
                 C
                                                                                                                     STEPS
          Part No.  A  B  C  D                                    Description                                 Kg
          304-1  156  62  13  140 LED Strip Light. Non-Switched. 12/24 Volt. White Body. IP68 Waterproof. 10 Watt.  0.14
          304-2  156  62  13  140 LED Strip Light. Touch Sensitive Switch. 12/24 Volt. White Body. IP68 Waterproof. 10 Watt.  0.14
          304-3  156  62  13  140 LED Strip Light. PIR Sensor 45 Second. 12/24 Volt. White Body. IP68 Waterproof. 10 Watt.  0.14
          304-4  207  62  13  191 LED Strip Light. Non-Switched. 12/24 Volt. White Body. IP68 Waterproof. 10 Watt.  0.19
          304-5  207  62  13  191 LED Strip Light. Touch Sensitive Switch. 12/24 Volt. White Body. IP68 Waterproof. 10 Watt.  0.19  VENTILATION
          304-6  207  62  13  191 LED Strip Light. PIR Sensor 45 Seconds. 12/24 Volt. White Body. IP68 Waterproof. 10 Watt.  0.19
