VENTILATION

Roof Ventilators

ELECTRICAL

Roof Ventilator Flettner Ventilators

„ White ABS dome with black ABS tray - low profile „ Part No. 1999 Adaptor for double skinned roofs up to 50mm
„ Can be used as a low rate extract vent on stand alone fitment, thick.
or as an intake vent on forced air applications.
„ Cutout hole size 238 - 240mm.
A EMERGENCY

B
E
C
D
2000 GENERAL
F
G 1999
H

HANDLES

Part No. A B C D E F G H Kg Finish
2000 225 98 94 189 36 0.93 BP
Part No. A B C D Kg Finish 2000W 225 98 94 189 36 0.825 WP
HINGES
371 313 385 71 238 1.02 WP 1999 145 98 50 0.08 BP

Flettner Ventilators Low Profile Flettner Ventilator

„ High performance TCX version of original 2000 Ventilator. „ This Slimline LPV vent has been specifically designed for
„ Part No. 2001NB Is a narrow base version for ribbed roofs. customers who have fitted roof-racks etc and therefore
require a lower profile ventilator.
„ TCX-2 Adapter for 2000 and 2001NB IRONWORK
„ Flettner has designed the Slimline in such a way that it ‘Fits
any Roof.’ As with all Flettner’s there is a lifetime warranty as
standard.

LIGHTING

A
A
B B LOCKS
C
ROOF G D C
D
E
F
STEPS
Part No. A B C D E F G Kg Finish
Ventilator
2001 260 98 19 1-10 40 198 145 1.185 BP Part No. A B C D Kg Finish
2001W 260 98 19 1-10 40 198 145 1.2 WP Ventilator
2001NB 260 98 19 1-10 40 198 108 1.19 BP 2002 252 58 117 66 0.705 BP
Adaptor Adapter VENTILATION
TCX-2 0.32 BP 2002-1 0.275
