Figure 1-48. Rocker Rotation

s0247x1x 2.19

Using a dial or beam type torque wrench, rotate the rigid fork pivot stud and rocker through the arc shown. The torque reading should be 25-35 in- If the torque reading in the previous step is out of specifi- cation, adjust the bearing retainer to obtain a 25-35 in- NOTE If you feel metal to metal contact (grinding while moving the See Figure 1-47. Attach the spring fork legs (8) to the rockers by installing the pivot studs (5) (thick head), from the inboard side, with washers (2) and nuts (1) (acorn on FXSTS/hex on FLSTSC). Tighten nuts to 45-50 ft-lbs 2.32 FRONT Install front wheel. See 2.6 FRONT WHEEL: FLSTSC or Install front brake caliper and b

Figure 1-48. lbs (2.8-4.0 Nm). lbs (2.8-4.0 Nm) reading. rocker), replace the spherical bearings. (61.0-67.8 Nm). On FLSTSC only, install fender. See FENDER: FLSTSC. 2.7 FRONT WHEEL: FXSTS. FRONT BRAKE CALIPER: FLSTSC BRAKE CALIPER: FXSTS. 2006 Softail: Maintenance
