TAPTITE 2000® – Thread-rolling in metals
What length screw for which thread Ø?
Nominal thread Ø M2.5 M3 M3.5 M4 M5 M6 M8 M10
TAPTITE 2000® Standard length range
Length L (mm)
3 ± 0,375
4 ± 0,375
5 ± 0,375
6 ± 0,375
8 ± 0,45
10 ± 0,45
12 ± 0,55
(14) ± 0,55
16 ± 0,55
18 ± 0,55
20 ± 0,65
(22) ± 0,65
25 ± 0,65
(28) ± 0,65
30 ± 0,65
35 ± 0,80
40 ± 0,80
45 ± 0,80
50 ± 0,80
55 ± 0,95
60 ± 0,95
70 ± 0,95
80 ± 0,95
Intermediate lengths on request. not for countersunk heads
Lengths in brackets should be avoided as far as possible.
