2020 DRAG RACING

SB Ford "The Hammer" Aluminum Cylinder Heads BB Chevy Aluminum Cylinder Heads
As-cast aluminum heads are engi- NEW! Much more affordable than NEW!
neered for street/strip small block most competitors' aftermarket
Ford 289-351W applications that op- aluminum cylinder heads,
erate 7200-7400 RPM. Full .750" thick quality Flotek heads for big block
decks provide durability to high-compression, Chevys are offered in 290cc, 315cc,
blown, or nitrous applications, while raised .750" 320cc, and 360cc intake runner versions. Cylinder
exhaust ports provide improved coolant flow. Fully heads include bronze wall valve guides, high-temperature
assembled heads are complete with 2.080" intake and 1.600" exhaust seats, and a five-angle valve job. Heads are assembled with
exhaust valves, high-performance valve springs, hardened locks and retain- 2.250" or 2.300" intake and 1.880" exhaust valves, high-performance
ers, positive valve seals, and 3/8" screw-in rocker studs. Sold each. valve springs, hardened locks and retainers, positive valve seals, 7/16"
Intake Comb. Int. Exh. screw-in rocker studs, and guide plates. Sold each.
Part No. Description Runner Chamber Valve Valve Intake Comb. Int. Exh. Max.
FTC2205-HR-505 The Hammer, Hyd. Roller 205cc 60cc 2.080" 1.600" Part No. Description Runner Chamber Valve Valve Lift
FTC2205-SR-505 The Hammer, Solid Roller 205cc 60cc 2.080" 1.600" FTC290-6056 Oval Port, Assem., Hyd. Roller 290cc 112cc 2.300" 1.880" .725"
FTC290-6058 Oval Port, Assem., Solid Roller 290cc 112cc 2.300" 1.880" .750"
SB Ford Aluminum Cylinder Heads FTC305-6056 Rect. Port, Assem., Hyd. Roller 320cc 133cc 2.250" 1.880" .725"
FTC305-6058 Rect. Port, Assem., Solid Roller 320cc 133cc 2.250" 1.880" .750"
High-performance alumi- FTC315-6056 Rect. Port, Assem., Hyd. Roller 315cc 121cc 2.300" 1.880" .725"
num cylinder heads deliver FTC315-6058 Rect. Port, Assem., Solid Roller 315cc 121cc 2.300" 1.880" .750"
exceptional flow to small FTC360-6056 Rect. Port, Assem., Hyd. Roller 360cc 121cc 2.250" 1.880" .725"
2.250" 1.880" .750"
block Ford engines. Bare FTC360-6058 Rect. Port, Assem., Solid Roller 360cc 121cc 2.250" 1.880" .725"
FTC407-6056 Rect. Port, Assem., Hyd. Roller
360cc
133cc
heads have bronze valve FTC407-6058 Rect. Port, Assem., Solid Roller 360cc 133cc 2.250" 1.880" .750"
guides and five-angle valve job, while fully assembled versions add stainless
steel swirl-polished valves, high-performance valve springs, hardened BB Chevy CNC “Jackal” Aluminum Cylinder Heads
locks and retainers, PC valve seals, choice of pedestal mount or 3/8" Flotek’s largest, most powerful cyl-
screw-in rocker studs, and 5/16" guide plates. Choose from 180cc or fully inder head for 540-576 cu. in. big NEW!
CNC-machined 190cc intake runner heads with 58cc or 60cc combustion block Chevys is fully CNC-ported.
chambers. Sold individually as bare or fully assembled. Heads accept stock pistons, have
Intake Comb. Int. Exh. raised valve cover rails, and exhaust
Part No. Description Runner Chamber Valve Valve port location is raised .360". Heads are as-
Bare Cylinder Heads
FTC203500 Bare Cyl. Head 180cc 58cc 1.940" 1.540" sembled with 2.350" intake and 1.880" exhaust
Assembled Cylinder Heads valves, high-performance valve springs, hardened locks
FTC203505 Assy. Cyl. Head/Pedestal Mount 180cc 58cc 1.940" 1.540" and retainers, positive valve seals, 7/16" screw-in rocker studs,
Assembled Cylinder Heads With CNC-Machined Intake/Exhaust Runners
FTC2190-HRCNC-505 Assy./Stud Mount/Hyd. Roller 190cc 60cc 2.020" 1.600" and guide plates. Sold each.
Intake Comb. Int. Exh. Max.
SB Chevy Aluminum Cylinder Heads Part No. Description Runner Chamber Valve Valve Lift
FTC375-5058 Rect. Port, Assem., Solid Roller 375cc 127cc 2.350" 1.880" .850"
An affordable high-flowing FTC375-5059 Rect. Port, Assem., Solid Roller 375cc 127cc 2.350" 1.880" .950"
aluminum head for popular
small block Chevys. Bare
heads include bronze valve
guides and five-angle valve
job, while assembled versions add stainless steel swirl polished valves,
high- performance valve springs, hardened locks and retainers, PC valve
seals, 3/8" screw-in rocker studs, and 5/16" guide plates. Choose from
180cc or 200cc runner heads with 64cc or 69cc combustion chambers. Sold
individually as bare or fully assembled.
Intake Comb. Spark Int. Exh.
Part No. Description Runner Chamber Plug Valve Valve
Bare Cylinder Heads
FTC101500 Bare Cyl. Head 180cc 64cc Angle 2.020" 1.600"
FTC102500 Bare Cyl. Head 180cc 64cc Straight 2.020" 1.600"
Assembled Cylinder Heads
FTC101505 Assy. Cyl. Head 180cc 64cc Angle 2.020" 1.600"
FTC102505 Assy. Cyl. Head 180cc 64cc Straight 2.020" 1.600"
FTC1200-HRAC-505A Assy./Hyd. Roller 200cc 64cc Angle 2.020" 1.600"

Photo By: Ashley Kindle Russ Reist

315
