Page 624 - 2018 Racecar Engineering Drag Racing Parts and Accessories Catalog

Swivel Hose Ends AN Flare Adapters
Dash “A” “B”
Part No. Size Part No. Dash Size Dash Size
Straight Aluminum Female Swivel Union
TXRHF-20004-BLK -4 TXRHF-31033-BLK -3 -3
TXRHF-20006-BLK -6 TXRHF-31044-BLK -4 -4
TXRHF-20008-BLK -8 TXRHF-31066-BLK -6 -6 A B
TXRHF-20010-BLK -10 TXRHF-31068-BLK -6 -8
TXRHF-20012-BLK -12 TXRHF-31088-BLK -8 -8
TXRHF-20016-BLK -16 TXRHF-31080-BLK -8 -10
30° Aluminum Male Union
TXRHF-23004-BLK -4 TXRHF-32033-BLK -3 -3
TXRHF-23006-BLK -6 TXRHF-32044-BLK -4 -4 A B
TXRHF-23008-BLK -8 TXRHF-32066-BLK -6 -6
TXRHF-23010-BLK -10 TXRHF-32088-BLK -8 -8
TXRHF-23012-BLK -12 TXRHF-32010-BLK -10 -10
TXRHF-23016-BLK -16 TXRHF-32012-BLK -12 -12
45° TXRHF-32016-BLK -16 -16
TXRHF-24504-BLK -4 Aluminum 90° Union
TXRHF-24506-BLK -6 TXRHF-35933-BLK -3 -3
A
TXRHF-24508-BLK -8 TXRHF-35944-BLK -4 -4
TXRHF-24510-BLK -10 TXRHF-35966-BLK -6 -6
TXRHF-24512-BLK -12 TXRHF-35988-BLK -8 -8
TXRHF-24516-BLK -16 TXRHF-35910-BLK -10 -10
60° TXRHF-35912-BLK -12 -12
TXRHF-26004-BLK -4 Aluminum Male Reducer B
TXRHF-26006-BLK -6 TXRHF-36304-BLK -3 -4
TXRHF-26008-BLK -8 TXRHF-36406-BLK -4 -6
TXRHF-26010-BLK -10 TXRHF-36410-BLK -4 -10
TXRHF-26012-BLK -12 TXRHF-36412-BLK -4 -12 A B
TXRHF-26016-BLK -16 TXRHF-36608-BLK -6 -8
90° TXRHF-36610-BLK -6 -10
TXRHF-29004-BLK -4 TXRHF-36810-BLK -8 -10
TXRHF-29006-BLK -6 TXRHF-36812-BLK -8 -12
TXRHF-29008-BLK -8 TXRHF-36012-BLK -10 -12
B
TXRHF-29010-BLK -10 TXRHF-36016-BLK -10 -16
TXRHF-29012-BLK -12 TXRHF-36216-BLK -12 -16
TXRHF-29016-BLK -16 Aluminum 45° Female Coupler
120° TXRHF-34516-BLK -16 -16 A
TXRHF-22004-BLK -4 Aluminum Swivel Reducer
TXRHF-22006-BLK -6 TXRHF-37304-BLK -3 -4
TXRHF-22008-BLK -8 TXRHF-37406-BLK -4 -6
TXRHF-22010-BLK -10 TXRHF-37408-BLK -4 -8
TXRHF-22012-BLK -12 TXRHF-37608-BLK -6 -8 A B
TXRHF-22016-BLK -16 TXRHF-37610-BLK -6 -10
150° TXRHF-37810-BLK -8 -10
TXRHF-25004-BLK -4 TXRHF-37812-BLK -8 -12
TXRHF-25006-BLK -6 TXRHF-37012-BLK -10 -12
TXRHF-25008-BLK -8 TXRHF-37016-BLK -10 -16
TXRHF-25010-BLK -10 TXRHF-37216-BLK -12 -16
TXRHF-25012-BLK -12 Aluminum Swivel Flare Expander
TXRHF-25016-BLK -16 TXRHF-38304-BLK -3 -4
180° TXRHF-38306-BLK -4 -6
TXRHF-28004-BLK -4 TXRHF-38608-BLK -6 -8 A B
TXRHF-28006-BLK -6 TXRHF-38810-BLK -8 -10
TXRHF-28008-BLK -8 TXRHF-38012-BLK -10 -12
TXRHF-28010-BLK -10 TXRHF-38620-BLK -16 -20
TXRHF-28012-BLK -12
TXRHF-28016-BLK -16
