P. 33
BRAKE
Brake Bias Adjuster Electric Right Front
With Reference Pointer Brake Shut-Off ALL48017
Know exactly where brake adjustments Disable right front brake with the flip of a
are set–no more guessing the cor- ALL42078 switch. Commonly found on dirt modified and
rect setting. When the adjusting late models, electric shut-off helps turn the car on
knob is turned, the pointer entry when track conditions are heavy/wet. Kit
moves along the reference electronically disables the right front brake yet allows
scale. Adjuster body can be brake pressure to bleed-off from the right front brake caliper,
pivoted for easy viewing unlike manual shut off valves. Detailed installation instructions
and multiple applica- are included.
tions. Record where the pointer
is located and use as baseline. Brake Shut-Off Valve
Housing, internals, brackets and
knob with detent are all made ALL42074 ALL48010
of aluminum. Each includes a Valve has 1/8"NPT inlet and outlet and is
five foot cable that can be cut to rated at 2,000 PSI. Use Allstar ALL50120
any length for a custom fit and fitting for 3/16" inverted flare brake line.
has 3/8"-24 threads for most standard Dimensions: 1/2" W x 1-3/4" L x 1-9/16" H.
pedal assemblies.
ALL42074 ..... Adjuster With Knob RF Brake Shut-Off Valve Decal
ALL42078 ..... Adjuster With Crank Handle ALL48011
Replacement Parts Decal has a 5/8" hole and is designed for use
ALL99116 ..... Cable Assembly with the ALL48010 valve.
ALL99117 ..... Ball, Spring And Set Screw
Brake Bias Gauge Panels
Brake Bias Adjusters Gauges show actual front and rear line pres-
Adjust brake bias from the sure for making brake bias changes before
or during the race. Pre-assembled units have
driver seat to compensate 0-1500psi liquid filled gauges with 1/8"NPT
for changing track condi- male fittings and bleeder valves to
tions. Adjusters mount to ALL42072 evacuate air from the gauges. 2-3/4" x
balance bars with 3/8"-24 4-1/2" pre-drilled panels are offered in
threads. Two styles avail- horizontal or vertical versions.
able: heavy duty crank or cable
with knob. ALL80170 ..... Vertical
ALL80172 ..... Horizontal
ALL42070 Swivel Head
ALL42070 Brake Pressure Gauge ALL11020
Gauge temporarily replaces the bleeder screw in
most aftermarket brake calipers with 1/4"-28
thread bleeder screws to measure brake pressure.
Swivel head positions the 2-3/4" diameter gauge for
ALL42071
easy viewing. Convenient remote bleeder can be used
to evacuate air in the system for accurate readings.
ALL42070 ..... Short Heavy Duty Steel Crank-Style Adjuster Related Part ALL11022
ALL42071 ..... Long Heavy Duty Steel Crank-Style Adjuster ALL11022 ...... Adapter converts ALL11020 and
ALL42072 ..... 5 Ft. Long Cable-Style Adjuster other gauges with 1/4"-28 thread to 10mm-1.50
thread for use with popular GM metric calipers.
ALL99116 ..... Replacement Cable Assembly
Brake Pressure
Gauge Kit ALL11026
Brake pressure gauge kit includes
two gauges, allowing one gauge
to be used in the front and one
in the rear brake system. Compare front to rear pressures
to help diagnose problems or to preset your brake bias.
Gauges easily replace 1/4"-28 brake bleeders which are
David Mielke Photo: JohnnyB Imagery commonly found in most aftermarket calipers.
