Plastic Tank Radiators Late Model COOLING
Uniquely designed plastic tank radiators with aluminum Radiator ALL30044
core offer over a 22% gross weight savings to comparable Aluminum dual pass
aluminum tank radiators when filled with coolant. These radiator has 16"x28"
performance radiators also provide 6% better cooling overall dimensions and
than aluminum tank radiators. Tanks are fastened to the does not have a filler neck.
core with multi-clamps and an o-ring gasket, a process The 1-3/4" bottom outlet
similar in design to many of today’s high performance late is welded 90 degrees to the NEW!
model muscle cars. Corrosion resistant tanks have molded tank, not angled, as these radiators typically mount
in 1-1/2" inlet and 1-3/4" with the top leaned forward. Universal top inlet design
beaded hose outlets. Widths accepts 1-1/2" standard hose, 1-3/4" hose, -16 or -20an
are overall including tanks. fittings (sold separately). Includes a 1/4" petcock located
near the top on the driver’s side to release possible air in
Single Pass the system when filling.
Core WxH Overall
GM Sprint Radiator ALL30028
ALL30050 17" x 18" 22" x 19" Aluminum radiator with furnace
ALL30051 19" x 18" 24" x 19" brazed tanks provides superior
ALL30052 21" x 18" 26" x 19" ALL30052 cooling in sprint applications. Features
ALL30053 23" x 18" 28" x 19" machined filler neck, 1-1/2" RH
ALL30054 26" x 18" 31" x 19"
bottom outlet and (4) female top
Ford outlet ports for use with -10AN
ALL30320 17" x 18" 22" x 19"
ALL30321 19" x 18" 24" x 19" O-ring fittings. Radiator uses a smaller
ALL30322 21" x 18" 26" x 19" diameter cap (not included) such as
ALL30324 23" x 18" 28" x 19" ALL30124 or ALL30125. 20" wide x
ALL30326 26" x 18" 31" x 19" 22" tall x 2" wide. 9.7 lbs.

Sprint Cross Flow Radiator
ALL30322
(Chassis Mount)
Dual Pass ALL30030
GM Core WxH Overall Aluminum radiator with a
ALL30056 19" x 18" 24" x 19" unique black thermal coating
ALL30057 21" x 18" 26" x 19" provides superior cooling!
ALL30058 23" x 18" 28" x 19" Built-in mounting brackets
ALL30059 26" x 18" 31" x 19"
enable the radiator to be quick-
turn fastened directly to frame
tabs. Radiator with -10AN O-ring
ALL30572 inlets and 1-1/2" outlet is 20-1/2" wide x
TECH TIP
18-1/2" tall (including outlet neck) x 2-3/8" thick
Radiators with plastic tanks are recommended core. Recommended radiator cap is ALL30126
to use radiator caps rated at 25 lbs. or less. (28-32 lbs.) sold separately. Approximate weight
8.5 lbs.
Popular Radiator Caps
For Plastic Tank Radiators
ALL30135
ALL30135 ..... Stant Round 21–25psi Non-Recovery Wall Mount
ALL30137 ..... Stant Octagon 21–25psi Recovery Radiator Holder Kit ALL12216
Brackets fasten to trailer wall and
Upper Mount Kit hold radiator safely in place to
For Plastic Tank Radiators ALL30152 avoid damage during transport.
Channel rests on top of the core and two flat aluminum Kit includes two 29" long alu-
straps may be bolted or welded to the channel. Hook the minum brackets with adjustment
steel springs into provided hole and connect to a lower holes at 2" increments and arms
chassis location. Kit includes channel (1-1/2" x to fit radiator cores up to 2-1/4"
21-1/2"), two straps (1" x 11-1/2") and wide. Adjustable arms are slotted for quick
two 17" springs. adjustment with included thumbscrew knobs
to fit a variety of radiator heights.
Replacement Parts
ALL30122 ..... Spring
ALL30153 ..... Channel

www.allstarperformance.com 63
